ABB NTDI01 Digital I/O Termination Unit

DSDO110 ABB Advant OCS S100 I/O Board Brand New Original

Availability: 10 left in stock

Product Overview The ABB DSDO110 (57160001-K/3) serves as a high-density digital output interface for the Advant OCS, Symphony Plus, and...

SKU: DSDO110

Manufacturer: ABB
Product No.: DSDO110
Product Type: Digital Output Boards
Product Origin: Switzerland
Payment:T/T, Western Union
Weight: 375g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The ABB DSDO110 (57160001-K/3) serves as a high-density digital output interface for the Advant OCS, Symphony Plus, and S100 I/O systems. This module provides 32 independent channels designed to drive field actuators, interposing relays, and indicator panels across a broad 24V to 48V DC voltage range. It facilitates precise command execution from the central controller to the plant floor, ensuring seamless automation in utility-scale power generation and heavy industrial processes.

Technical Specifications

The DSDO110 utilizes a rugged Euro-card design, allowing for high-density installation within standard ABB subracks.

Attribute	Specification Details
Model Number	DSDO110
Part Number	57160001-K/3
Output Channels	32 Channels
Output Voltage Range	24 V DC to 48 V DC
Output Current	0.5 A per channel (Typical)
Isolation	Opto-isolated, 2500 V DC
System Compatibility	Advant OCS / Symphony Plus / S100 I/O
Power Consumption	+5V Modulebus: 45mA
Operating Temp	–25 °C to +55 °C
Dimensions	324 mm x 22.5 mm x 225 mm
Weight	0.375 kg
Country of Origin	Sweden

Engineering Advantages

The DSDO110 addresses the complex requirements of legacy system maintenance and modern process scaling:

Broad Voltage Flexibility: Unlike standard 24V-only cards, the DSDO110 operates effectively up to 48V DC. This wider window accommodates diverse field equipment and long cable runs where voltage drops might otherwise compromise signal integrity.
High-Integrity Isolation: 2500V opto-isolation decouples the sensitive logic of the Advant Master controller from field-side electrical transients. This protects your high-value CPU assets from catastrophic damage during field wiring faults or lightning-induced surges.
Optimal Heat Management: The Euro-card architecture facilitates efficient vertical airflow within the rack. This design prevents localized hotspots, extending the module's lifecycle even when all 32 channels operate at high duty cycles in non-climate-controlled environments.
Rapid Diagnostic Mapping: Integrated channel status monitoring allows the DCS to detect and report output discrepancies. Maintenance teams identify failed relays or broken field circuits directly from the HMI, eliminating the need for manual point-to-point hardware troubleshooting.

FAQs

Is this unit 100% Brand New?

Yes. We supply the ABB DSDO110 57160001-K/3 as a 100% Brand New and Original product. Each board ships in its original factory-sealed packaging with full manufacturer-traceable quality.

What is the difference between the DSDO110 and the DSDO115A?

The DSDO115A (3BSE018298R1) serves as the modern replacement for the DSDO110 in 24V systems. While the DSDO110 supports up to 48V, the DSDO115A is optimized specifically for 24V applications where the maximum load current does not exceed 150 mA.

Can I install the DSDO110 while the rack is powered?

Standard ABB safety guidelines for the S100 I/O system recommend powering down the subrack before inserting or removing Euro-cards. This prevents potential backplane arcing and ensures the system bus correctly initializes the new hardware.

Does this module include the terminal base?

No. The DSDO110 refers to the plug-in Euro-card (Digital Output Board) itself. It requires a compatible S100 I/O subrack and its associated terminal units for field wiring integration.
