Emerson KJ3001X1-BA1 DeltaV 8-Channel Discrete Input Module

Emerson DeltaV KJ3001X1-BA1 12P0549X112 8-Channel Discrete Input Module

Availability: 5 left in stock

DescriptionThe Emerson DeltaV KJ3001X1-BA1 (12P0549X112) is an 8-channel isolated discrete input module designed for the DeltaV M-Series automation system. This...

SKU: KJ3001X1-BA1 12P0549X112

Manufacturer: Emerson
Product No.: KJ3001X1-BA1 12P0549X112
Product Type: Discrete Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 280g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Emerson DeltaV KJ3001X1-BA1 (12P0549X112) is an 8-channel isolated discrete input module designed for the DeltaV M-Series automation system. This module provides reliable interface capabilities for 24 VDC field switches and sensors. By utilizing galvanic isolation, it ensures signal integrity and protects the system controller from electrical surges originating from the field side. It is engineered for demanding industrial environments, including oil refineries, chemical processing, and mining operations.

Features

8-channel isolated discrete input architecture.
Galvanic isolation for enhanced signal protection.
Supports hot-swapping for reduced maintenance downtime.
Mechanical rotary keying (Position B2) to prevent incorrect module insertion.
Certified for use in hazardous atmosphere locations.
No calibration required; maintenance-free design.

Technical Specifications

Parameter	Specification
Model	KJ3001X1-BA1 (12P0549X112)
Series	DeltaV M-Series
LocalBus Power	12 VDC at 100 mA
Field Circuit Rating	24 VDC at 5 mA per channel
Operating Temperature	0 to 60 deg C
Relative Humidity	5 to 95 percent (Non-Condensing)
Hazardous Rating	II 3 G / EEx nA IIC T4 (Nemko 02ATEX431U)
Shock Resistance	10g 1/2 Sinewave for 11 msec
Vibration Resistance	1 mm P-P (5-16 Hz); 0.5g (16-150 Hz)
Contaminant Rating	ISA-S71.04-1985 Class G3

Installation Guidelines

Ensure the system power is disconnected before installing or removing the module from the I/O carrier.
Verify the mechanical rotary keying on the terminal block is set to Position B2 to match the module.
Handle the module using ESD-safe practices to prevent damage to internal circuitry.
Ensure the module is fully seated in the carrier to maintain proper electrical contact and environmental protection.
Route field wiring away from high-voltage or high-EMI sources to maintain signal accuracy.
Ensure adequate ventilation is provided to maintain ambient temperatures within the specified 0 to 60 deg C range.

FAQ

Is this module hot-swappable?

Yes, the KJ3001X1-BA1 supports hot-swapping within the DeltaV M-Series carrier, allowing for replacement without shutting down the entire system, provided standard safety procedures are followed.

What is the purpose of the keying system?

The mechanical rotary keying at Position B2 is a safety feature designed to prevent the accidental insertion of an incompatible I/O card into a slot configured for a specific type of signal.
