Emerson EPRO MMS3120/022-000 Machinery Protection Card

Availability: 99 left in stock

Product Overview The Emerson EPRO MMS3120/022-000 serves as a specialized dual-channel monitor for absolute bearing vibration within the MMS3000 machinery protection framework....

SKU: MMS3120/022-000

Manufacturer: Emerson
Product No.: MMS3120/022-000
Product Type: Bearing Vibration Monitoring
Product Origin: USA
Payment:T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Emerson EPRO MMS3120/022-000 serves as a specialized dual-channel monitor for absolute bearing vibration within the MMS3000 machinery protection framework. Unlike displacement-only modules, this card processes signals from electrodynamic velocity sensors to track the vibration of the machine housing and bearing pedestals. It provides a critical safety layer for steam turbines, high-pressure compressors, and industrial fans by identifying mechanical imbalances and structural resonance in real-time. We offer this unit as 100% Brand New and Factory Sealed, ensuring your machinery protection system maintains original manufacturer specifications.

Technical Specifications

The MMS3120/022-000 integrates high-fidelity analog conditioning with standardized industrial outputs.

Parameter	Specification
Model Number	MMS3120/022-000
Input Channels	2 Independent Channels (Simultaneous Monitoring)
Sensor Compatibility	Electrodynamic Velocity Sensors (e.g., PR9268 series)
Measurement Type	Absolute Bearing Vibration (Velocity/Displacement)
Communication	RS-485 (Standard), Optional Profibus DP-V1
Output Signal	0 – 10 V DC (Conditioned Signal)
Power Supply	24 V DC Nominal
Operating Temp	-20°C to +70°C
Dimensions	120 mm x 80 mm x 35 mm

Engineering Advantages

Absolute Vibration Tracking: This module measures the vibration of the bearing housing relative to free space. This data proves essential for identifying structural issues, such as loose footings or pedestal cracks, which proximity probes (measuring relative shaft movement) might miss.
Redundant Machine Protection: Dual-channel inputs allow for the simultaneous monitoring of two separate bearings or two axes on a single bearing. This setup supports comprehensive machine health snapshots and redundant alarm logic.
High-Temperature Performance: The module’s internal components handle the elevated ambient temperatures found in turbine halls and petrochemical processing plants, maintaining signal linearity without thermal drift.
Seamless Legacy Integration: The MMS3120/022-000 provides a direct replacement for aging cards in existing MMS3000 racks. It maintains full compatibility with legacy backplanes while offering modern signal processing accuracy.

FAQs

Can I use eddy current proximity probes with the MMS3120/022-000?

The MMS3120/022-000 is specifically configured for electrodynamic velocity sensors. If your application requires monitoring relative shaft displacement using eddy current probes (PR6423 series), you should select the /022-100 variant or a dedicated displacement module.
How does this module handle sensor cable faults?

The module incorporates an "OK-Circuit" monitoring function. It constantly checks the impedance of the connected velocity sensors. If the circuit detects an open or short, it instantly triggers a "Channel Not OK" alert and inhibits relay outputs to prevent a false machine trip.
What is the primary maintenance requirement for this card?

Beyond verifying the 24V DC supply stability, you should periodically test the alert and danger relay thresholds. Use the MMS3000 configuration software to simulate vibration levels and ensure the trip logic executes correctly at the DCS/PLC level.
Is the MMS3120/022-000 hot-swappable?

While the MMS3000 rack supports the physical insertion of cards during power-on, you must place the corresponding control loop into "Bypass" or "Manual" mode at the DCS to avoid accidental emergency shutdowns during the exchange.
