The GE DS200LDCCH1AKA, also cataloged as the LDCC Drive Control/LAN Communications Board, operates as a dedicated hardware component for high-speed signal processing and multi-bus network bridging within GE Mark V Turbine Control and DIRECTO-MATIC 2000 drive systems.
Suffix Breakdown & Model Matrix
| Revision/Component | Designator Code | Functional Meaning |
|---|---|---|
| Base Board Architecture | DS200 | Standard GE Mark V PCB baseline layout |
| Functional Acronym | LDCC | Drive Control and LAN Communication Board |
| Coating Type | H | Conformal coating applied for environmental protection |
| 1st Functional Revision | A | Initial baseline functional circuit update |
| 2nd Functional Revision | K | Secondary functional modification iteration |
| Artwork Revision | A | PCB trace layout and silk screen artwork iteration |
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DS200LDCCH1AKA |
| Brand | GE (General Electric) |
| Origin | USA |
| Weight | 1.25 kg |
| Dimensions | Standard Mark V full-height card size |
| Operating Temp | 0 to 60 deg C |
| Power Consumption | 24 VDC backplane bus supplied |
| Product Series | Speedtronic Mark V / DIRECTO-MATIC 2000 |
| Onboard Processors | LCP, DCP, MCP, CMP (Quad-processor architecture) |
| User Interface | Alphanumeric keypad with diagnostic display, DN1 bar graph LEDs |
| Memory Architecture | 6 Flash PROMs for firmware, EEPROM for parameter storage |
| Conformally Coated | Yes (Type H designator) |
Industrial Control & Drive Communications
The DS200LDCCH1AKA utilizes backplane bus communication velocity and deterministic protocol execution via four integrated microprocessors. The LAN Control Processor (LCP) converts up to five distinct bus interfaces, enabling multi-node system orchestration. Deterministic motor control loops are handled directly by the Motor Control Processor (MCP) and Co-Motor Processor (CMP), providing processing power for field-oriented vector calculations and actuator feedback execution without incurring interface latency. Firm-level parameters reside in onboard EEPROM modules to allow seamless field configuration updates while maintaining firmware compatibility across DIRECTO-MATIC 2000 drive setups.
Frequently Asked Questions
Q: What is the functional isolation provided by the conformal coating option on this module?
A: The conformal coating on the DS200LDCCH1AKA provides barrier protection against airborne particulates, humidity, and conductive contaminants, protecting trace integrity without impacting heat sink dissipation profiles.
Q: Can the board undergo a hard reset without cycling total system power?
A: Yes, a local reset can be triggered via the onboard tactile RESET pushbutton for fatal operational faults, or via soft command execution through the operator interface without disrupting main system power.
Field Installation Guidelines
- Ensure the control cabinet is powered down and standard Electrostatic Discharge (ESD) wrist straps are grounded before removing the card from its static-shielding bag.
- Verify board jumper locations against the original system configuration before sliding the card into the Mark V rack assembly.
- Fasten the LAN interface board stiffening stab connector to maximize mechanical stability and shield continuity in high-noise environments.
- Align edge card connectors carefully with backplane sockets to avoid pin damage; apply firm, steady pressure until full engagement is achieved.
- Verify signal and communication wiring shields are tied to the dedicated earth ground bar using short, low-impedance pigtails to prevent noise interference on high-speed bus lines.
