GE Fanuc IC200ALG240 VersaMax Analog Input Module

GE Fanuc IC200ALG240 VersaMax Analog Input Module

Availability: 10 left in stock

GE Fanuc IC200ALG240 VersaMax Isolated Analog Input Module Configured for high-precision analog signal acquisition in VersaMax PLC platforms, the GE...

SKU: IC200ALG240

Manufacturer: GE Fanuc
Product No.: IC200ALG240
Product Type: Analog Input Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

GE Fanuc IC200ALG240 VersaMax Isolated Analog Input Module

Configured for high-precision analog signal acquisition in VersaMax PLC platforms, the GE Fanuc IC200ALG240 (IC200ALG240 Analog Input Module) provides direct physical/electrical execution. This module processes eight independent voltage and current input channels, transferring converted 16-bit digital values directly across the backplane bus to host processor units.

Suffix Breakdown & Model Matrix

Part Number / Matrix	Base Model	Series / Line	Input Type	Isolation Level
IC200ALG240	IC200ALG240	VersaMax I/O	8-Channel 16-Bit Analog	Full Channel-to-Channel

Hardware Specifications

Parameter	Specification
Model	IC200ALG240
Brand	GE Fanuc (Emerson)
Origin	USA
Weight	0.2 kg
Dimensions	11.0 cm x 6.68 cm x 5.0 cm
Operating Temp	0 deg C to +60 deg C
Power Consumption	Backplane: 15 mA max at 5 VDC; External: 100 mA max at 24 VDC
Input Channels	8 channels (channel-to-channel isolated)
Resolution	16-Bit (381 nA current / 381 uV voltage)
Voltage Ranges	+/-10 VDC, 0 to 10 VDC
Current Ranges	4-20 mA, 0-20 mA
Input Impedance	Voltage: >1 Mohm; Current: 250 ohm
System Accuracy	+/-0.1% of full scale at 25 deg C
Isolation Rating	Channel-to-channel and Channel-to-Backplane (Galvanic)

Backplane Bus Communication Velocity & Deterministic Network Integrity

The IC200ALG240 interfaces with the main controller via the high-velocity VersaMax backplane bus, drawing a minimal 15 mA current at 5 VDC. System logic receives updated 16-bit analog values every 16.7 ms at 60 Hz or 20 ms at 50 Hz filter settings. Channel-to-channel and channel-to-backplane galvanic isolation eliminates ground loops and limits cross-talk noise during high-density I/O density scaling, maintaining signal fidelity across deterministic network architectures.

Frequently Asked Questions

Q: What is the backplane current draw for the IC200ALG240 module?

A: The module draws a maximum of 15 mA at 5 VDC directly from the VersaMax logic backplane bus.

Q: How does channel-to-channel galvanic isolation affect module operation during field fault conditions?

A: Full channel-to-channel galvanic isolation prevents ground potential differences and electrical faults on one channel from propagating to adjacent channels or compromising backplane logic circuits.

Q: Is hot-swapping supported for this module on the VersaMax carrier?

A: Yes, operators can perform live module replacement on the active carrier base, provided field power is safely isolated prior to removal.

Field Installation Guidelines

Follow these standardized procedures when installing and wiring the module in industrial panels:

Snap the carrier base onto the standard DIN rail and ensure the mechanical latch firmly grips the rail.
Insert the IC200ALG240 module vertically into the carrier connector until both side locking tabs click into position.
Wire signal lines using twisted-pair shielded cable, connecting shields to the terminal strip earth ground points to minimize electromagnetic interference.
Verify that external 24 VDC field power (19.5 VDC to 30 VDC operating range) is correctly wired to the carrier power terminals.
Keep signal wiring separated from high-voltage AC lines and motor drive outputs within wire ducting to maintain specified 16-bit measurement accuracy.
