Configured for high-speed network communication and control data routing in PACSystems Rx7i platforms, the GE Fanuc IC698ETM001 (IC698ETM001 Ethernet Interface Module) provides direct physical/electrical execution.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IC698ETM001 |
| Brand | GE Fanuc |
| Origin | USA / As specified on label |
| Weight | 0.92 lbs (0.42 kg) |
| Dimensions | Standard Rx7i double-slot / single-slot chassis form factor |
| Operating Temp | 0 to 60 deg C |
| Power Consumption | Powered directly via Rx7i backplane bus |
| Network Protocols | TCP/IP, SRTP, EGD (Ethernet Global Data) |
| Interface Ports | 2 x Ethernet ports (10BaseT / 100BaseTX) |
| Connector Type | Shielded 8-pin female RJ-45 |
| Operational Mode | Standalone communications coprocessor |
Backplane Bus Communication Velocity and Deterministic Networks
The IC698ETM001 operates as an independent communications processor, executing TCP/IP, SRTP, and Ethernet Global Data (EGD) protocols across dual 10/100 Mbps RJ-45 ports. By offloading network packet management from the primary controller CPU, the module preserves backplane bus communication velocity and optimizes data exchanges across deterministic networks. Its dual-port interface allows multi-node network topologies without requiring external switching infrastructure for basic node links.
Frequently Asked Questions
Q: Which network protocols are natively supported by the IC698ETM001 Ethernet module?
A: The IC698ETM001 natively supports TCP/IP, SRTP (Server Request Transfer Protocol), and EGD (Ethernet Global Data) communications over 10BaseT and 100BaseTX physical layers.
Q: What connector types are utilized for network cabling on the IC698ETM001 front panel?
A: The module features two standard shielded 8-pin female RJ-45 connectors for 10/100 Ethernet twisted-pair copper connections.
Field Installation Guidelines
- Insert the module vertically into the dedicated backplane slot of the Rx7i rack with the main power isolated to prevent pin damage.
- Secure upper and lower retaining screws on the module panel to ensure mechanical frame ground continuity.
- Connect CAT5e or CAT6 shielded twisted-pair cables directly to the RJ-45 ports, ensuring the cable shield is bonded at the cabinet entry gland.
- Maintain minimum separation distance between Ethernet network cables and high-voltage power wiring to prevent signal degradation.
