The GE IS200ERIOH1ABC, also cataloged as the IS200ERIO Exciter Regulator I/O Board, operates as a dedicated hardware component for customer and system signal interfacing within GE EX2100 Excitation Systems and Mark VI platforms. Mounting into ERBP or ERRB backplanes, the card routes control signals across ECTBG2, EPCT, EROC, ERDD, and ERRR terminal boards to execute real-time excitation regulation across simplex and redundant loops.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS200ERIOH1ABC (IS200ERIO) |
| Brand | GE (General Electric) |
| Origin | USA |
| Operating Temp | -30 to 65 deg C |
| Power Consumption | System Backplane Bus Powered |
| Application Configurations | Simplex and Redundant EX2100 Excitation Systems |
| Onboard Processing | Field Programmable Gate Array (FPGA) with Dual Port Memory (DPM) |
| Backplane Connections | ERBP (Simplex) / ERRB (Redundant) Backplane Bus |
| Interface Connectors | Dual 25-pin D-sub connectors to backplane |
| Terminal Board Compatibility | ECTBG2, EPCT, EROC, ERDD, and ERRR terminal boards |
Deterministic Network Backplane Bus Velocity and FPGA Processing
The IS200ERIOH1ABC utilizes an onboard Field Programmable Gate Array (FPGA) to execute high-speed data acquisition directly into Dual Port Memory (DPM), optimizing backplane bus communication velocity across the EX2100 control architecture. Integrated firmware flash compatibility across the FPGA logic array allows synchronized signal scaling across high-density I/O connections. Physical interconnections via dual 25-pin backplane connectors maintain deterministic communication paths between customer field terminals and core excitation processors without transmission delays.
Frequently Asked Questions
Q: How differs the backplane installation between simplex and redundant configurations for the IS200ERIOH1ABC?
A: In simplex control systems, the card mounts to an ERBP (Exciter Regulator Backplane), whereas in redundant configurations, it interfaces via an ERRB (Exciter Regulator Redundant Relay Backplane) to route signals to the ERRR board.
Q: What onboard architecture handles real-time I/O data acquisition on the board?
A: Signal storage and high-speed data acquisition are managed by a dedicated Field Programmable Gate Array (FPGA) interfacing directly with onboard Dual Port Memory (DPM).
Q: How are external terminal boards connected to the IS200ERIOH1ABC?
A: The board interfaces with customer and system terminal boards (EPCT, ECTBG2) through two 25-pin high-density connectors mated directly to the underlying backplane.
