IC200ALG331-GD VersaMax PLC 4-20mA 0-10V Input Card

Availability: 99 left in stock

Product Overview The GE IC200ALG331-GD functions as a high-precision interface for capturing real-time environmental and process data within the VersaMax I/O family....

SKU: IC200ALG331-GD

Manufacturer: GE Fanuc
Product No.: IC200ALG331-GD
Product Type: Industrial Data Acquisition
Product Origin: USA
Payment:T/T, Western Union
Weight: 550g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The GE IC200ALG331-GD functions as a high-precision interface for capturing real-time environmental and process data within the VersaMax I/O family. This module converts external analog signals—such as pressure, temperature, or flow data—into precise digital values for the PLC CPU. We provide this unit as 100% Brand New and Original, ensuring the highest level of measurement accuracy and component longevity for mission-critical utilities and energy monitoring systems.

Technical Specifications

The IC200ALG331-GD provides high-density signal acquisition with the following technical parameters:

Parameter	Specification
Channels	8 Analog Inputs
Resolution	12-Bit (0 to 4095 counts)
Input Voltage Range	0 to 10 VDC, ±10 VDC
Input Current Range	4 to 20 mA
Input Impedance	Voltage: 1 MΩ / Current: 250 Ω
Accuracy	±0.25% of Full Scale
Update Rate	1 ms per channel
Isolation	250 VAC continuous (Optical)
Backplane Power	5 VDC (Approx. 130 mA)
Diagnostics	Field power loss detection & channel fault reporting
Operating Temp	0°C to 60°C

Engineering Advantages

The IC200ALG331-GD design solves specific integration challenges in complex industrial environments:

Signal Versatility: This module accepts both voltage (±10V) and current (4-20mA) inputs. This flexibility allows engineers to standardize on a single module type for diverse sensors, reducing spare parts inventory and simplifying rack configuration.
High-Speed Data Processing: With a 1ms per channel update rate, the module captures rapid process fluctuations. This speed ensures the control loop responds immediately to pressure spikes or flow changes in dynamic manufacturing environments.
Superior Noise Immunity: Integrated optical isolation protects the PLC backplane from ground loops and high-frequency electrical noise common in power plants. This barrier maintains signal integrity even when field wiring runs parallel to high-voltage motor cables.
Proactive Fault Monitoring: Built-in diagnostics detect field power loss and individual channel faults. The module reports these errors directly to the CPU, allowing maintenance teams to identify broken wires or sensor failures without manual circuit testing.

FAQs

Does the IC200ALG331-GD require external configuration software?

You configure the input ranges (Voltage vs. Current) through the VersaMax CPU configuration tool. The module hardware supports these ranges natively once the parameters are downloaded from the PLC.
What is the difference between the "GD" suffix and the standard IC200ALG331?

The "GD" designation typically refers to specific manufacturing standards or hardware revisions optimized for global distribution. It remains fully functional and compatible with standard VersaMax carriers and CPUs.
How should I wire the module to minimize interference?

Use shielded, twisted-pair cabling for all analog signals. Terminate the shield at the frame ground of the PLC rack to ensure the 250 VAC optical isolation effectively filters out electromagnetic interference (EMI).
Can this module detect a "broken wire" in 4-20mA mode?

Yes. Because the 4-20mA standard uses a non-zero live offset, the module identifies a 0mA signal as a "low alarm" or fault condition, allowing for immediate notification of signal loss.
