The GE IC200UEX624, also cataloged as the IC200UEX Analog Input Expansion Module, operates as a dedicated hardware component for multi-channel analog signal acquisition within VersaMax Micro PLC platforms. The module provides physical interface termination and signal conditioning for up to 4 analog channels configurable for current or voltage loops, transmitting digitized field measurements across the local expansion bus.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IC200UEX624 |
| Brand | GE |
| Origin | USA / Standard Industrial Operations |
| Product Type | Analog Input Modules |
| Analog Inputs | 4 Channels (Voltage / Current selectable) |
| Input Voltage Range | Nominal 24 VDC (-20% to +25%) |
| Power Consumption | 3 Watts |
| Hold-up Time | 10 ms at 19.2 VDC |
| Inrush Current | 1 A maximum at 30 VDC |
| Dimensions | Standard VersaMax Micro expansion footprint |
| Weight | Standard expansion module weight |
| Operating Temp | 0 to +60 deg C |
Backplane Bus Communication Velocity and Deterministic Networks
The expansion interface conditions voltage and current signals to match CPU execution speed, preserving deterministic cycles over local expansion channels and connected EtherNet/IP networks. Fast execution loops prevent signal processing bottlenecks across high-density I/O configurations. Internal logic pathways maintain complete firmware flash compatibility with the host CPU, allowing live logic modifications and memory module synchronization without interrupting analog sampling routines.
Frequently Asked Questions
Q: How does the IC200UEX624 analog module maintain bus power during momentary voltage drops?
A: The onboard power supply circuit incorporates a hold-up time capability of 10 ms at 19.2 VDC to survive transient power dips without dropping signal acquisition.
Q: Can the IC200UEX624 module be configured while the main controller is running?
A: Yes, the unit supports online programming changes through the host controller, allowing memory module updates and logic modifications without stopping execution.
Field Installation Guidelines
- Power Disconnection: Isolate external 24 VDC system power before physically connecting or disconnecting the expansion module to the VersaMax Micro main unit.
- Bus Connector Alignment: Align the side expansion connector pins straight into the main controller header to prevent pin bending during mechanical coupling.
- Signal Wiring Separation: Route 4-20 mA current loops and low-level voltage input cables in dedicated raceways separated from 120/230 VAC wiring to minimize electromagnetic noise pickup.
- Ground Bonding: Connect the expansion base frame to a common panel ground bus using low-impedance grounding straps.
