Product Overview
The IC694ALG223A functions as a high-density analog current interface for the PACSystems RX3i platform. It converts standard industrial current signals (0-20 mA and 4-20 mA) from field transmitters into precise 12-bit digital data. This module optimizes rack space by providing 16 single-ended channels in a single slot, making it a cornerstone for complex process monitoring in chemical, water treatment, and power generation sectors. We offer this product as 100% Brand New and Original to ensure maximum system integrity.
Technical Specifications
This module interfaces directly with the RX3i backplane, utilizing high-speed bus communication for rapid data refresh.
| Feature | Specification |
| Input Channels | 16 Single-Ended |
| Input Ranges | 0 to 20 mA, 4 to 20 mA, 4 to 20 mA Enhanced |
| Resolution | 12-bit (approx. 4 µA per LSB) |
| Update Rate | 13 ms (all channels) |
| Accuracy | ±0.25% of Full Scale @ 25°C |
| Input Impedance | 250 Ohms |
| Internal Power | 120 mA @ 5 VDC |
| External Supply | 20 to 30 VDC (User Supplied) |
| Isolation | 1500 VAC between field side and logic side |
Engineering Advantages
-
Fault Detection via Enhanced Range: The "Enhanced 4-20 mA" mode identifies open-wire conditions. If the signal drops below 4 mA, the module triggers a diagnostic alarm, allowing operators to distinguish between a zero-process value and a physical wiring failure.
-
Space-Saving High Density: By packing 16 channels into a single RX3i slot, the IC694ALG223A reduces total hardware footprint and backplane requirements, lowering the overall cost of the control system.
-
Superior Noise Rejection: A built-in 19 Hz low-pass filter suppresses high-frequency electrical noise common in motor-heavy industrial environments, ensuring stable process variables for PID loops.
-
Hot-Swap Capability: Within the RX3i architecture, this module supports hot-swapping (under specific configuration), which minimizes downtime during maintenance or module replacement.
FAQs
Q: Does the IC694ALG223A require an external power supply?
A: Yes. While the module draws 120 mA from the 5V backplane bus for logic, you must provide a 24 VDC external supply to power the analog input circuitry.
Q: Can I mix 0-20 mA and 4-20 mA signals on the same module?
A: Yes. The PACSystems RX3i configuration software allows you to define the input range on a per-channel basis, providing flexibility for diverse sensor types.
Q: What is the primary difference between the "A" version and the base IC694ALG223?
A: The "A" suffix typically denotes the latest manufacturing revision or firmware update. The IC694ALG223A remains fully backward compatible with all RX3i systems supporting the ALG223 series.
Q: How does the module handle a sensor failure?
A: In "Enhanced" mode, the module detects current values below the 4 mA threshold. It reports this as an "Under Range" or "Open Wire" fault through the PLC's diagnostic table, enabling rapid troubleshooting.
