IC694CEE001 GE Fanuc RX3i Expansion Carrier

IC694CEE001 PACSystems RX3i Expansion Carrier | GE Fanuc

IC694CEE001 PACSystems RX3i Expansion Carrier | GE Fanuc

Availability: 10 left in stock

The GE Fanuc IC694CEE001, also cataloged as the IC694CEE001 Expansion Carrier, operates as a dedicated hardware component for extending I/O...

SKU: IC694CEE001

Manufacturer: GE Fanuc
Product No.: IC694CEE001
Product Type: Communication Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 260g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

The GE Fanuc IC694CEE001, also cataloged as the IC694CEE001 Expansion Carrier, operates as a dedicated hardware component for extending I/O slot capacity within PACSystems RX3i platforms.

Hardware Specifications

Parameter	Specification
Model	IC694CEE001
Brand	GE Fanuc Emerson
Origin	United States
Weight	0.56 lbs (0.26 kg)
Dimensions	Standard RX3i expansion footprint
Operating Temp	0 to +60 deg C
Power Consumption	Powered via host CEP001 carrier (24 VDC bus, 700 mA rated current)
Slot Configuration	2 slots total (1 on CEP001 host + 1 on CEE001 expansion)
Target Modules	IC694 I/O modules
Network Interface	PROFINET I/O LAN
I/O Data Capacity	1024 bytes maximum
Enclosure Rating	IP20
Mounting Options	DIN Rail or Panel Mount
Storage Temp	-40 to +85 deg C
Humidity	5% to 95% non-condensing

Profinet Deterministic Networks and I/O Density Scaling

The IC694CEE001 expands local station backplane capacity by adding a secondary physical interface slot for IC694 modules while maintaining integration across Profinet deterministic networks. By routing power and data buses directly through the host CEP001 carrier, the assembly executes I/O density scaling up to the 1024-byte system limit without requiring redundant external power drops or software reconfigurations. Backplane bus communication velocity and firmware flash compatibility remain synchronized across both carrier slots during real-time data transport.

Frequently Asked Questions

Q: How is primary operating power supplied to the IC694CEE001 expansion carrier?

A: The IC694CEE001 receives its internal operating power directly from the connected host CEP001 carrier module via the local backplane interface, drawing up to 700 mA at 24 VDC nominal.

Q: Which module types are supported in the expansion slot of the IC694CEE001?

A: The expansion slot on the IC694CEE001 is designed specifically to accept standard PACSystems RX3i IC694 series I/O modules.

Q: What environmental enclosure considerations apply to installing this module?

A: The IC694CEE001 carries an IP20 ingress protection rating and must be installed inside a clean, dry control enclosure that provides protection against dust and moisture.

Field Installation Guidelines

De-energize power to the host CEP001 carrier and surrounding backplane hardware prior to mechanical installation.
Mount the IC694CEE001 carrier onto a standard 35 mm DIN rail or fasten securely to an enclosure panel using mechanical hardware.
Align and seat the inter-carrier backplane connector to establish physical and electrical continuity with the host CEP001 module.
Insert the target IC694 I/O module into the CEE001 expansion slot, ensuring terminal block wiring remains isolated from live bus voltage.
Verify that all field wiring cable shields are grounded at the system earth ground bus to suppress electromagnetic noise before applying 24 VDC system power.
