The GE IC697CPM915, also cataloged as the IC697CPM915 Central Processing Unit, operates as a dedicated hardware component for high-speed logic execution and floating-point computations within Series 90-70 rack systems.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IC697CPM915 |
| Brand | GE Fanuc Emerson |
| Origin | USA / Global Manufacturing |
| Weight | 0.96 kg (2.13 lbs) |
| Dimensions | Standard Series 90-70 Single-Slot Rack Form Factor |
| Operating Temp | 0 to 60 deg C |
| Power Consumption | 70 W (2.8 A at 5 VDC) |
| Series | Series 90-70 |
| Product Type | Central Processing Units |
| Microprocessor | 32-bit Intel 80486DX |
| Clock Speed | 32 MHz |
| Floating Point Math | Hardware Floating Point Architecture supported |
| Boolean Execution Speed | 0.4 microseconds per function |
| Maximum I/O Capacity | Up to 12,000 mixed discrete inputs/outputs |
| Status Indicators | 4 Green LEDs |
Backplane Bus Communication Velocity and System Integration
The IC697CPM915 executes high-speed signal processing and floating-point logic routines using a 32-bit Intel 80486DX microprocessor running at 32 MHz. The unit exchanges data directly over the Series 90-70 rack backplane, maximizing backplane bus communication velocity and enabling execution speeds as fast as 0.4 microseconds per Boolean function.
To preserve program state integrity during operations, firmware flash compatibility supports structured logic updates, while the CPU handles up to 12,000 mixed discrete input and output signals. Real-time I/O density scaling allows seamless expansion across remote and expansion racks without interrupting internal bus arbitration cycles. Four front-panel green LEDs provide immediate diagnostic feedback regarding backplane power, system status, and memory execution state.
Frequently Asked Questions
Q: What are the exact backplane voltage and current requirements for the IC697CPM915?
A: The module operates at 5 VDC nominal and draws 2.8 A, resulting in a total power consumption of 70 W.
Q: What processor architecture powers the IC697CPM915 logic engine?
A: The CPU is powered by a 32-bit Intel 80486DX processor running at 32 MHz with integrated hardware floating-point support.
Q: How many total discrete I/O points can be addressed by this processor?
A: The IC697CPM915 can address and process up to 12,000 mixed discrete input and output points.
Field Installation Guidelines
- Always verify that main backplane rack power is completely isolated before inserting or removing the CPU module from the slot.
- Ensure proper mechanical engagement of the upper and lower card guides before fully seating the module into the Series 90-70 backplane.
- Maintain clean ground bonding between the chassis DIN/rack frame and protective earth to mitigate electrical noise across high-speed bus lines.
- Keep clearance around the rack enclosure ventilation openings to prevent ambient temperatures from exceeding 60 deg C during 70 W thermal loading.
- Check front-panel status LEDs immediately after power application to verify proper backplane startup and CPU initialization.
