MMG1070/02TS EPRO Shaft Vibration Signal Conditioner

Availability: 99 left in stock

Product Overview The Emerson EPRO MMG1070/02TS functions as a high-precision signal conditioning module designed for non-contact displacement and vibration measurements. It integrates...

SKU: MMG1070/02TS

Manufacturer: Emerson
Product No.: MMG1070/02TS
Product Type: Vibration Monitoring
Product Origin: USA
Payment:T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Emerson EPRO MMG1070/02TS functions as a high-precision signal conditioning module designed for non-contact displacement and vibration measurements. It integrates seamlessly with EPRO’s MMS monitoring ecosystem to process raw inputs from eddy current probes (PR6422/PR6423 series). This module translates complex electromagnetic induction data into standardized industrial signals, allowing operators to monitor shaft position and radial vibration in real-time. We offer this unit as 100% Brand New and Factory Sealed, ensuring your critical rotating assets remain protected by original manufacturer specifications.

Technical Specifications

The MMG1070/02TS provides dual-channel signal acquisition with high thermal stability.

Parameter	Specification
Model Number	MMG1070/02TS
Input Channels	2 Independent Channels (Dual-channel configuration)
Measurement Type	Shaft Vibration, Radial Displacement, Axial Position
Supported Sensors	PR6422, PR6423 series Eddy Current Probes
Communication	RS-485 (Standard), Optional Profibus DP-V1
Analog Output	0 – 10 V DC (Conditioned Signal)
Power Supply	+24 V DC Nominal
Operating Temp	-20°C to +70°C
Weight	0.3 kg
Dimensions	4.1 cm x 15.9 cm x 10.8 cm

Engineering Advantages

Optimized Signal Linearization: The MMG1070/02TS converts the non-linear raw voltage from proximity sensors into a strictly linear 0-10V output. This precision allows your DCS or PLC to calculate exact micrometer-level displacements without additional software scaling.
Redundant Machine Monitoring: Dual-channel inputs support X/Y axis probe setups. This enables the module to provide the data required for shaft orbit analysis, which is essential for identifying mechanical rubs, unbalance, or oil whip.
Automatic Calibration & Compensation: Built-in circuitry compensates for probe aging and temperature drift. This feature maintains measurement accuracy over long-term operation, even in high-heat environments typical of steam turbine housings.
Rugged Industrial Housing: The module utilizes a compact, shielded design that rejects electromagnetic interference (EMI). This prevents "signal ghosting" or false vibration spikes caused by nearby high-power motor drives.

FAQs

Can the MMG1070/02TS replace the MMG1070/04TS?

The MMG1070/02TS and /04TS variants often differ in specific channel configurations or firmware presets (such as measurement range or filter settings). While they belong to the same family, you must verify the scale factor ( $$V/mm$$ ) in your system configuration to ensure compatibility before swapping units.
What is the primary indicator of a successful installation?

After physical mounting, check the "Gap Voltage" at the test points. For PR6423 sensors, a stable reading near -10V DC indicates the probe is perfectly centered in its linear measurement range. The MMG1070/02TS front panel LEDs will also indicate a "Channel OK" status.
Does this module support hot-swapping?

The MMS framework generally allows for hot-swapping, but we recommend placing the specific monitoring loop in "Bypass" or "Manual" mode at the control room level to prevent an accidental machinery trip during the exchange.
Is the 12-month warranty globally applicable?

Yes. We provide a full 12-month warranty on this brand-new unit, covering any manufacturing defects under standard industrial operating conditions.
