Product Overview The ABB DSDO131 (57160001-KX) functions as a high-versatility 16-channel relay output interface for the Advant OCS, Symphony Plus,...

SKU: DSDO131

Manufacturer: ABB
Product No.: DSDO131
Product Type: 240V AC/DC Switching
Product Origin: Switzerland
Payment:T/T, Western Union
Weight: 440g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The ABB DSDO131 (57160001-KX) functions as a high-versatility 16-channel relay output interface for the Advant OCS, Symphony Plus, and S100 I/O platforms. Unlike standard solid-state modules, the DSDO131 utilizes mechanical relays to switch both AC and DC loads across a wide voltage spectrum (0-240V). This module provides the necessary isolation and power handling to control high-wattage actuators, solenoids, and interposing motor starters directly from the DCS backplane. We supply this unit as a 100% Brand New and Original component to guarantee long-term operational integrity in mission-critical environments.

Technical Specifications

The DSDO131 combines the high-density Euro-card format with robust relay-based switching capabilities.

Attribute	Specification Details
Model Number	DSDO131
Part Number	57160001-KX
Output Type	Relay (Electromechanical)
Channels	16 Isolated Channels
Voltage Range	0 - 240 V AC/DC
Max Load (DC)	48 W
Max Load (AC)	720 VA
Isolation	2500 V Opto-isolated logic interface
System Compatibility	Advant OCS / Symphony Plus / S100 I/O
Operating Temp	–25 °C to +55 °C
Storage Temp	–40 °C to +70 °C
Unit Weight	0.7 kg

Engineering Advantages

The DSDO131 solves distinct industrial switching challenges through its electromechanical architecture:

Universal Load Compatibility: The relay-based design enables the module to switch mixed load types—including both AC and DC—on the same board. This flexibility eliminates the need for separate AC and DC output cards, significantly reducing the spare parts footprint for multi-fuel power plants and petrochemical facilities.
High-Voltage Switching Power: Capable of handling up to 240V, the DSDO131 drives heavy-duty industrial solenoids and contactors without requiring additional external interposing relays. This reduces cabinet wiring complexity and minimizes potential failure points between the DCS and field hardware.
Superior Galvanic Protection: 2500V opto-isolation protects the internal system bus from field-side voltage spikes. The physical air gap of the relay contacts provides a secondary layer of protection, preventing low-level leakage currents common in solid-state modules from accidentally triggering sensitive field devices.
Ruggedized Diagnostic Feedback: Integrated status indicators provide real-time visual verification of each relay state. This allows maintenance personnel to verify command execution from the controller at a glance, accelerating troubleshooting in high-pressure operational scenarios.

FAQs

Is the DSDO131 a direct replacement for solid-state digital output modules?

The DSDO131 serves applications requiring higher voltage or AC switching that solid-state DC modules cannot handle. However, because it uses mechanical relays, it has a finite mechanical life compared to solid-state boards. We recommend using the DSDO131 for power-switching tasks rather than high-frequency pulse applications.

Can I switch different voltages on different channels of the same board?

Yes. Since each relay output provides dry contact or isolated switching (depending on your specific terminal unit wiring), you can manage different voltage levels across the 16 channels, provided you maintain proper clearance and isolation at the terminal base.

What is the maximum frequency of switching for this relay board?

Due to the mechanical nature of relays, the DSDO131 suits periodic switching tasks. It should not be used for PWM (Pulse Width Modulation) or rapid-cycling control loops, as frequent cycling will prematurely wear out the internal relay contacts.

Is this unit compatible with the S100 I/O rack used in AC800M systems?

Absolutely. The DSDO131 fully integrates with the S100 I/O subracks common in Advant Master and AC800M lifecycles, ensuring a seamless fit for system expansions or legacy hardware replacements.
