Product Overview

The ABB RET316*4 (Part Number: HESG448750M2) serves as a high-performance numerical protection solution for medium- and high-voltage power transformers. This digital relay provides specialized 87T differential protection alongside multi-functional monitoring for two-winding, three-winding, and autotransformers. It safeguards critical infrastructure—including generator step-up units—against internal faults, thermal stress, and abnormal voltage conditions. We offer this unit as 100% Brand New and Original, ensuring compliance with the highest utility standards for grid stability and rapid fault clearance.

Technical Specifications

Parameter	Specification
Model Number	RET316*4 (HESG448750M2)
Protection Type	Numerical Differential (87T)
Application	2-Winding, 3-Winding, Autotransformers, GSU Units
Integrated Functions	Overcurrent, Thermal Overload, Voltage Protection
Operating Temperature	–10°C to +55°C
Mounting Format	Compact Module / Rack Mount
Dimensions (H×W×D)	192 mm × 96 mm × 175 mm
Net Weight	1.5 kg

Engineering Advantages

Selective Fault Discrimination: The RET316*4 utilizes sophisticated numerical logic to distinguish between internal transformer faults and external "through-faults." This selectivity prevents unnecessary trips during external surges while ensuring instantaneous isolation of internal winding failures.
Comprehensive Asset Safeguarding: Beyond differential protection, the unit integrates thermal overload modeling and overcurrent supervision. This multi-layered approach protects the transformer's insulation from long-term degradation caused by overheating and harmonic stress.
Optimized for Modernization: The compact 96mm-wide module format allows engineers to install advanced digital protection in legacy panels with limited space. This makes the RET316*4 an ideal choice for retrofitting older utility substations without requiring extensive cabinet modifications.
Rapid Fault Clearance: The relay executes protection algorithms at high speeds to minimize the "let-through" energy during a fault. This rapid response prevents catastrophic tank ruptures and limits damage to the transformer core and bushings.
Programmable Flexibility: Programmable I/O logic enables seamless integration with existing SCADA and substation automation architectures. The relay handles complex interlocking and signaling requirements without the need for auxiliary logic hardware.

FAQs

Is the ABB RET316*4 HESG448750M2 suitable for autotransformers?

Yes. The numerical logic specifically supports the unique protection requirements of autotransformers and three-winding configurations, including the necessary compensation for phase shifts and current ratio mismatches.

How does the unit handle magnetizing inrush current?

The RET316*4 incorporates advanced harmonic restraint features. It analyzes the second harmonic component of the current to identify transformer energization (inrush) and prevents the differential protection from tripping incorrectly during startup.

What is the condition of this HESG448750M2 unit?

We guarantee this unit is 100% Brand New and Original. It ships in its original factory packaging with all relevant serial numbers intact, ensuring it meets original ABB performance specifications for mission-critical power systems.

Does this relay require specific software for configuration?

Configuration typically requires ABB’s dedicated protection engineering software. We recommend verifying compatibility with your current software version or consulting the technical manual for communication parameters before installation.
