Schneider Electric TSXDEZ12D2 Modicon Micro Discrete Input Module

Availability: 1 left in stock

DescriptionThe Schneider Electric TSXDEZ12D2 is a high-performance discrete input module designed for integration within the Modicon TSX Micro programmable controller...

SKU: TSXDEZ12D2

Manufacturer: Schneider Electric
Product No.: TSXDEZ12D2
Product Type: Discrete Input Module
Product Origin: France
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Schneider Electric TSXDEZ12D2 is a high-performance discrete input module designed for integration within the Modicon TSX Micro programmable controller platform. This module provides reliable signal acquisition for industrial automation tasks, supporting a variety of sensor types to ensure flexible system configuration.

Features

12 discrete input channels for comprehensive monitoring of field devices.
Compatible with 2-wire and 3-wire proximity sensors.
Supports both PNP and NPN input configurations for versatile wiring.
Designed for seamless integration into the Modicon Micro architecture.
Input impedance rating of 2.4 kOhm for stable signal processing.

Applications

This module is engineered for use in industrial control systems requiring digital signal input, such as machine tool control, automated assembly lines, and packaging equipment where proximity sensing is critical for process sequencing.

Technical Specifications

Model Number	TSXDEZ12D2
Module Type	Discrete Input Module
Number of Inputs	12
Sensor Compatibility	2-wire/3-wire proximity sensors
Logic Compatibility	PNP/NPN
Input Impedance	2.4 kOhm
Manufacturer	Schneider Electric

Installation Guidelines

Ensure the PLC rack power is disconnected before installing or removing the module.
Mount the module securely in the designated slot of the Modicon TSX Micro base unit.
Use shielded cables for input wiring to minimize electromagnetic interference (EMI) in high-noise environments.
Verify input voltage polarity matches the sensor output type (PNP vs NPN) during field wiring.
Maintain proper ventilation around the controller rack to prevent overheating during continuous operation.
Handle with care to prevent electrostatic discharge (ESD) damage to sensitive internal circuitry.

FAQ

Is the TSXDEZ12D2 compatible with both PNP and NPN sensors?
Yes, the module is designed to accommodate both PNP and NPN sensor configurations, providing flexibility for various field device requirements.

How many inputs does this module provide?
The TSXDEZ12D2 module features 12 discrete input channels.
