Description
The Woodward 5462-744 is a high-performance I/O module designed for the MicroNet control platform. This module provides essential input and output interfacing capabilities for industrial control applications, ensuring reliable signal processing and system integration within Woodward-based automation architectures.
Features
- Designed specifically for the Woodward MicroNet control system.
- Provides 16 isolated digital inputs for 24 V dc signal monitoring.
- Includes 2 analog outputs configured for 4–20 mA control signals.
- Optimized for low power consumption with a typical rating of 6 W.
- Robust design suitable for standard industrial operating environments.
Technical Specifications
| Product Model | 5462-744 |
| Manufacturer | Woodward |
| System Compatibility | MicroNet |
| Supply Voltage | 24 V dc |
| Module Consumption | 6 W (typical) |
| Digital Inputs | 16 x 24 V dc |
| Analog Outputs | 2 x 4–20 mA |
| Operating Temperature | 0 degC to +60 degC |
| Storage Temperature | -40 degC to +85 degC |
| Humidity | 5% to 95% RH (non-condensing) |
Installation Guidelines
- Ensure the MicroNet rack is powered down before inserting or removing the 5462-744 module to prevent electrical damage or system faults.
- Verify that the 24 V dc power supply is stable and within the specified operating range before energizing the module.
- Maintain proper grounding practices for all I/O cabling to minimize electromagnetic interference (EMI).
- Ensure adequate ventilation around the rack to maintain ambient temperatures within the 0 degC to +60 degC operating range.
- Handle the module using ESD-safe procedures to protect internal electronic components from static discharge.
FAQ
Is the Woodward 5462-744 compatible with other control systems?
This module is specifically engineered for the Woodward MicroNet control platform. It is not intended for use in non-Woodward control systems.
What is the typical power consumption of this module?
The 5462-744 module has a typical power consumption of 6 W when operating within its rated 24 V dc supply voltage.
What are the storage requirements for this module?
The module should be stored in a dry, non-condensing environment within a temperature range of -40 degC to +85 degC to ensure long-term reliability.
