Westinghouse Ovation 5X00241G01 Series Datasheet & Technical Manual

Availability: 99 left in stock

Westinghouse 5X00241G01 Ovation Series The Westinghouse 5X00241G01, also cataloged as the 5X00241G01 Processor Module, operates as a dedicated hardware component...

SKU: 5X00241G01

Manufacturer: Emerson
Product No.: 5X00241G01
Product Type: Westinghouse Ovation Series
Product Origin: USA
Payment:T/T, Western Union
Weight: 380g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Westinghouse 5X00241G01 Ovation Series

The Westinghouse 5X00241G01, also cataloged as the 5X00241G01 Processor Module, operates as a dedicated hardware component for executing logic and managing I/O communications within Ovation DCS platforms.

Hardware Specifications

Parameter	Specification
Model	5X00241G01
Brand	Westinghouse (Emerson)
Origin	United States
Weight	0.38 kg (0.85 lbs)
Dimensions	12.5 x 5.3 x 16.5 cm
Operating Temp	-40 to +70 deg C
Power Consumption	Rack powered via backplane
Processor Architecture	PowerPC 604e, 400 MHz, 64-bit
Memory Capacity	128 MB RAM
Storage Capacity	256 MB Flash
I/O Capacity	Up to 256 points
Communication Interfaces	Ethernet, RS-232, RS-485, CAN
Network Protocols	Modbus, EtherCAT, PowerLink

Process Control and DCS Instrumentation

The core computing platform utilizes a 64-bit PowerPC 604e processor clocked at 400 MHz to run deterministic control algorithms and process distributed data tables. Integrated channel-to-channel isolation on the communication buses protects the internal 128 MB RAM and 256 MB Flash storage layers against common-mode electrical transients. Serial and Ethernet physical layers interface with external subsystems using the Modbus protocol, while the system bus maintains low-latency synchronization with local and remote I/O subracks.

Frequently Asked Questions

Q: How is logic redundancy configured using the 5X00241G01 processor?

A: Redundant operations require two identical 5X00241G01 hardware modules installed in adjacent slots on a dual-chassis backplane. Synchronization cables link the processors to coordinate memory reflection and allow bumpless switchover execution in the event of a primary CPU failure.

Q: Can the onboard firmware and control application be modified during active execution?

A: Online changes are governed by the Ovation engineering software platform. Modifications to IEC 61131-3 logic can be compiled and downloaded to the 128 MB volatile memory partition while maintaining current I/O scan sequences, provided configuration parameters remain within execution limits.

Q: What action does the processor execute during a total backup power disruption?

A: Upon detection of a power loss threshold on the backplane bus, the module immediately commits non-volatile variables and configuration maps to the internal 256 MB Flash storage array before executing a controlled fail-safe state isolation routine.

Field Installation Guidelines

Earthing and Shield Alignment: Secure the module chassis directly to the backplane ground plane using the integrated retention screws. Ensure all communication line shields are single-point grounded to the cabinet master busbar to prevent ground loops.
Ambient Thermal Clearance: Verify that adjacent equipment placement allows unhindered convective vertical airflow through the chassis slot vents. The internal processor requires the ambient cabinet enclosure temperature to be stabilized between -40 and +70 deg C.
Communication Routing Restrictions: Route all high-speed Ethernet and serial data lines in isolated metallic conduits separated from high-voltage AC cabling and heavy switching relays to limit inductive electromagnetic noise coupling.
