Woodward 5501-380 MicroNet Power Supply Module

Availability: 6 left in stock

DescriptionThe Woodward 5501-380 is a dedicated AC-to-DC power supply module engineered for the MicroNet control system. This unit provides the...

SKU: 5501-380

Manufacturer: Woodward
Product No.: 5501-380
Product Type: PLC Power Supply
Product Origin: USA
Payment:T/T, Western Union
Weight: 2390g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Woodward 5501-380 is a dedicated AC-to-DC power supply module engineered for the MicroNet control system. This unit provides the necessary regulated DC power rails required to maintain stable operation of the MicroNet backplane and connected I/O modules. Designed for mission-critical industrial applications, including power generation, gas compression, and turbine control, the 5501-380 ensures consistent energy delivery in demanding environments. Its construction focuses on reliability and long-term performance, making it a standard choice for maintaining the integrity of MicroNet control racks.

Features

High-Efficiency Switching: Utilizes advanced switching topology to reduce power loss and minimize internal cabinet heat.
Integrated Protection: Includes built-in safety features such as over-voltage, over-current, and short-circuit protection to prevent damage to downstream electronic components.
EMI Filtering: Features internal circuitry to suppress line transients and electromagnetic interference, providing clean power to logic circuits.
Status Monitoring: Front-panel indicators allow for immediate visual confirmation of power status and fault diagnostics.
Robust Design: Engineered for panel mounting within industrial enclosures, supporting operation in temperatures ranging from 0 to 60 deg C.

Applications

This power supply is specifically designed for integration into Woodward MicroNet control systems. It is commonly deployed in critical infrastructure such as steam turbine management, large-scale power generation facilities, and gas compression stations where high availability and system uptime are mandatory.

Technical Specifications

Model	5501-380
Brand	Woodward
System Series	MicroNet
Input Voltage	120 VAC (Nominal)
Input Frequency	47 to 63 Hz
Mounting	Panel Mount
Operating Temperature	0 to 60 deg C
Weight	2.39 kg

Installation Guidelines

Power Isolation: Ensure the primary power source is fully disconnected before installing or removing the module from the chassis.
Cooling and Ventilation: Maintain adequate clearance around the module to allow for natural thermal convection. Avoid placing the unit near high-heat sources within the cabinet.
Grounding: Follow standard industrial grounding practices to ensure the chassis is connected to a common earth ground to mitigate EMI risks.
ESD Handling: Use proper electrostatic discharge (ESD) prevention measures when handling the module to protect internal circuitry.
Cable Routing: Keep AC input wiring separate from low-voltage signal cabling to prevent inductive noise coupling.

FAQ

What is the primary function of the 5501-380?

The 5501-380 acts as the primary power supply for the Woodward MicroNet system, converting 120 VAC utility power into the specific DC voltages required by the backplane and associated control modules.

Is this module suitable for high-temperature environments?

The module is rated for operation in ambient temperatures between 0 and 60 deg C, making it suitable for most standard industrial control room environments.

What should I do if the status indicator shows a fault?

First, verify that the input voltage is within the nominal 120 VAC range and that there are no short circuits on the secondary side. If the fault persists, refer to the MicroNet system maintenance manual for specific diagnostic codes.
