Yokogawa ADV551-P00 Digital Output Module

Configured for high-density signal distribution in CENTUM VP platforms, the Yokogawa ADV551-P00 (ADV551-P00 Digital Output Module) provides direct electrical execution of field device control and discrete state switching.

Suffix Breakdown & Model Matrix

Suffix Description
ADV551 Base Model: 32-Channel, 24 VDC, Isolated Digital Output
-P With Pushbutton Input
0 Without Status Display
0 Basic Type
/D5S00 Option: Pressure Clamp Terminal Block (ATD5S-00)



Hardware Specifications

Parameter Specification
Model ADV551-P00/D5S00
Brand Yokogawa
Origin Japan (Standard)
Weight 1.0 kg
Dimensions 125 x 130 x 248 mm
Operating Temp 0 deg C to 50 deg C
Power Consumption Via I/O Base Unit
Channel Capacity 32 Channels
Isolation 1500 VDC Field to System



Process Control and Channel-to-Channel Isolation

The ADV551-P00 operates as a discrete command interface between the field control station and field-mounted actuators or relays. Yokogawa engineers incorporate channel-to-channel isolation within the module architecture to suppress electromagnetic interference and prevent ground loops. This isolation maintains signal integrity during high-density switching operations. Furthermore, the module filters transient voltages to protect the internal logic circuits from noise generated by inductive field loads. Because the unit includes a pressure clamp terminal block, operators ensure high-reliability mechanical connections in vibration-sensitive environments.

Frequently Asked Questions

Q: Does the ADV551-P00 module support hot-swapping during normal system runtime? A: You may remove or insert the module while the system is powered, provided the I/O rack supports hot-swapping configurations. However, you must command the module to a "standby" or "test" state via the engineering station to prevent unexpected field device activation during the transition.

Q: How does the pushbutton input function on this module? A: The "P" suffix denotes integrated pushbutton input support. This feature allows operators to perform manual overrides or verification tests directly at the terminal level without requiring secondary logic processing from the main controller.

Field Installation Guidelines

  1. Mounting: Seat the ADV551-P00 firmly into the designated I/O base slot. Secure the module using the integrated locking mechanism to guarantee consistent contact with the backplane communication pins.
  2. Wiring: Connect the field actuators to the ATD5S-00 pressure clamp terminal block. You must ensure all wiring conforms to the cabinet's wire management specifications to prevent mechanical strain on the terminals.
  3. Grounding: Terminate the cable shields to the cabinet protective earth bar. Effective grounding prevents EMI from leaking into the output circuits, which ensures deterministic control of sensitive field actuators.
  4. Validation: Perform a loop check after installation. Verify that the output state corresponds to the command signal issued from the DCS, ensuring the pushbutton inputs are correctly mapped within the system configuration.
