M110 A Yokogawa HART Analog Input Output Module

التوفر: 10 متوفر في المخزون

Yokogawa M110 A Analog Input/Output Module Configured for high-speed network integration in industrial automation environments, the Yokogawa M110 A, also...

رمز المنتج: M110*A

Manufacturer: Yokogawa
Product No.: M110*A
Product Type: Analog Input/Output Modules
Product Origin: JAPAN
Payment:T/T, Western Union
Weight: 600g
Shipping port: Xiamen
Warranty: 12 months

وصف التقييمات

Yokogawa M110 A Analog Input/Output Module

Configured for high-speed network integration in industrial automation environments, the Yokogawa M110 A, also cataloged as the M110 Analog Input/Output Module, provides direct physical/electrical execution to manage analog signal transmission and simultaneous digital diagnostics. The hardware functions as a dedicated communication node on the system bus, routing field variables to distributed control system processors while executing real-time data frame validation.

Hardware Specifications

Parameter	Specification
Model	M110 A
Brand	Yokogawa
Origin	Japan
Weight	600 g
Dimensions	150 mm x 50 mm x 120 mm
Operating Temp	0 to 55 deg C
Power Consumption	Max 2.4 W (calculated from 24 VDC nominal)
Supply Voltage	24 VDC plus or minus 10%
Signal Support	Analog input/output with HART protocol
Redundancy	Dual-redundant configuration supported
Interface Type	Proprietary system bus connector
Communication Network	TCP/IP software based on BSD networking stack
Calibration Memory	Integrated EEPROM for factory defaults and user AD constants

Process Control & HART Protocol Integration

The module executes dual-channel operations, utilizing the 4-20 mA HART loop protocol to superimpose digital diagnostic data onto standard analog instrumentation lines. Internal frequency-shift keying (FSK) modems extract field device parameters without disrupting the analog primary variable loop. To ensure signal isolation, channel-to-channel isolation networks block high-voltage transients from crossing adjacent loops or damaging the backplane logic. The hardware memory system stores factory and user-defined analog-to-digital (AD) calibration values natively, maintaining measurement stability and drift suppression under varying thermal conditions within the control enclosure.

Frequently Asked Questions

Q: How does the module execute control when configured in a dual-redundant architecture?

A: Two modules operate side by side in dedicated backplane slots, sharing the identical I/O processing loop. The active unit handles communication over the system bus while the standby unit replicates calibration parameters and loop status data, ensuring an automatic bumpless switchover if the active unit encounters a hardware fault.

Q: Can the internal AD calibration storage be rewritten online during active loop monitoring?

A: No. User-defined AD calibration values must be uploaded and locked during commission or maintenance modes using proprietary Yokogawa engineering tools. This restriction prevents random memory overwrites from corrupting real-time analog signal processing during runtime.

Field Installation Guidelines

System Bus Engagement: Align the module with the chassis rack guides and push firmly until the proprietary system bus connector seats completely into the backplane matrix. Fasten all mounting screws to prevent connection drops caused by low-frequency industrial vibrations.
HART Loop Wiring: Route all analog I/O wiring using twisted shielded pairs to preserve the integrity of the high-frequency FSK digital signals. Keep communication lines separated from high-voltage AC cables by a minimum distance of 30 cm inside the wire ducting.
Cabinet Shield Grounding: Connect all field cable shields to a single instrument ground bar inside the cabinet housing. Do not ground the cable shield at both ends to avoid generating ground current loops that induce noise on the analog channels.
