The GE Fanuc IC697CHS750, also cataloged as the IC697CHS750 I/O Rack, operates as a dedicated hardware component for module interconnectivity and backplane bus signal distribution within GE Series 90-70 PLC systems.

Hardware Specifications

Parameter Specification
Model IC697CHS750
Brand GE Fanuc Emerson
Origin USA
Weight 8.88 lbs (4.03 kg)
Dimensions 11.15 in (H) x 12.60 in (W) x 7.50 in (D) [254 mm deep enclosure]
Operating Temp 0 to 60 deg C
Power Consumption Not specified (Passive backplane structure)
Rated Current 20 Amperes
Supply Voltage 5 VDC
Slot Capacity 5 slots
Enclosure Rating Open Enclosure, indoor use only
Cooling Type Convection airflow cooling
Mounting Type Rear mount mechanism
Series Compatibility GE Series 90-70 / IC697 PLC series

Backplane Bus Communication Velocity & I/O Density Scaling

The IC697CHS750 rack provides the physical housing and electrical backplane connectivity required for 5-slot Series 90-70 module configurations. Designed to maintain deterministic communication velocity across the backplane bus, the chassis structure routes high-speed data signals between processing units and expansion cards. The internal backplane power distribution supports up to 20 Amperes at 5 VDC to ensure stable voltage delivery across all populated slots. Firmware flash compatibility and noise-immune signaling are maintained across module backplane traces through dedicated grounding measures and rigid physical card guides.

Frequently Asked Questions

Q: How is power provided to individual modules installed in the IC697CHS750 chassis?

A: Modules populated within the 5 slots receive power via the internal backplane connector or through dedicated individual power supplies positioned on the left side of the module location.

Q: What physical clearance is required to maintain proper thermal dissipation for the rack?

A: The open enclosure relies on natural convection cooling. Unobstructed airflow pathways must be maintained between the chassis top/bottom ventilation spaces and nearby enclosure air outlets to prevent heat accumulation.

Q: How are field wiring connections secured to prevent mechanical strain on the backplane?

A: Field wiring passes through the bottom of the hinged door to access the removable terminal block, and an I/O terminal restraining strap on the side of the rack holds cables firmly in position.

Field Installation Guidelines

  1. Mount the IC697CHS750 chassis securely to a flat panel or enclosure backplate using the rear mounting holes. Ensure the mounting location is indoors and protected from environmental contaminants.
  2. Establish a low-impedance functional earth connection from the rack chassis ground point to the main panel ground bus to eliminate electrical noise interference.
  3. Align card modules carefully with the top and bottom slot guides before sliding them firmly into the backplane connectors.
  4. Route field wiring upward through the bottom opening of the hinged door. Secure all cable bundles using the side terminal restraining strap to prevent strain on the terminal connections.
  5. Verify that backplane J2 jumpers, if required by the system topology, are properly installed according to the Series 90-70 system expansion manual prior to applying primary power.
