Honeywell 51155506-140 Relay Cable Assembly

Honeywell 51155506-140 Experion LX Relay Cable Assembly

Availability: 5 left in stock

The Honeywell 51155506-140 is a high-performance relay cable assembly designed for integration within the Experion LX control system architecture. This...

SKU: 51155506-140

Manufacturer: Honeywell
Product No.: 51155506-140
Product Type: Cable Assembly
Product Origin: USA
Payment:T/T, Western Union
Weight: 150g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

The Honeywell 51155506-140 is a high-performance relay cable assembly designed for integration within the Experion LX control system architecture. This assembly facilitates reliable signal transmission for Digital Output (DO) source applications, ensuring robust connectivity in demanding industrial environments.

Features

Optimized for Digital Output (Source) configurations within the Experion LX platform.
Engineered for durability with a total length of 40.0 meters.
Designed to maintain signal integrity under rigorous industrial operating conditions.
Constructed to meet strict electrical isolation and resistance standards.

Technical Specifications

Product Model	51155506-140
Component Type	Relay Cable Assembly
Cable Length	40.0 Meters
Dielectric Strength	1000V AC (1 minute duration)
Conductor Resistance	≤25 Ohm/km (typical)
Operating Temperature	-40 degC to +85 degC
Storage Temperature	-50 degC to +90 degC
Humidity Tolerance	90% RH (non-condensing)

Installation Guidelines

Ensure all power is disconnected from the control system before routing or connecting the cable assembly.
Route cables away from high-voltage power lines and sources of electromagnetic interference (EMI) to prevent signal degradation.
Verify that the cable length is sufficient for the intended path, avoiding sharp bends that could stress the internal conductors.
Ensure all connector interfaces are fully seated and secured to maintain the required environmental seal and electrical contact.
Perform a continuity check after installation to confirm proper connection between the field device and the Experion LX I/O module.

FAQ

What is the primary application of this cable?
This assembly is specifically designed for Digital Output (Source) relay applications within Honeywell Experion LX control systems.

What are the environmental limits for this cable?
The cable is rated for operation between -40 degC and +85 degC, with a storage range of -50 degC to +90 degC, and can withstand humidity levels up to 90% RH non-condensing.
