Honeywell MU-GAIH13 High Level Analog Input Interface

Honeywell MU-GAIH13 High Level Analog Input Smart Transmitter Interface

Availability: 2 left in stock

DescriptionThe Honeywell MU-GAIH13 is a Field Termination Assembly (FTA) engineered for high-level analog input signal acquisition within Honeywell TPS and...

SKU: MU-GAIH13

Manufacturer: Honeywell
Product No.: MU-GAIH13
Product Type: Analog Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 750g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Honeywell MU-GAIH13 is a Field Termination Assembly (FTA) engineered for high-level analog input signal acquisition within Honeywell TPS and broader process automation environments. This interface module is specifically designed to manage up to 16 channels, facilitating the connection of 2-wire or 3-wire 4-20 mA smart transmitters. It provides isolated, floating DC power to field instrumentation, particularly in hazardous locations, while converting incoming currents into a 1 to 5 VDC signal for processing by compatible HLAI IOP modules. By ensuring precise signal repetition and robust electrical isolation, the MU-GAIH13 enhances system reliability and reduces the risk of signal degradation in complex industrial control architectures.

Features

Supports 16 individual analog input channels for high-density field integration.
Compatible with both 2-wire and 3-wire 4-20 mA DC smart transmitters.
Provides isolated floating DC power to support field-mounted devices in hazardous areas.
Converts field currents into a stable 1 to 5 VDC output for seamless DCS integration.
Designed for high-precision signal conditioning to mitigate noise and distortion.
Optimized for Honeywell TPS system compatibility.

Applications

This interface assembly is intended for use in mission-critical process environments, including:

Petrochemical and oil refining facilities.
Chemical processing and manufacturing plants.
Offshore oil and gas production platforms.
Thermal and utility power generation systems.

Technical Specifications

Model	MU-GAIH13
Channel Capacity	16
Input Signal	4-20 mA DC
Output Signal	1 to 5 VDC
Power Consumption	Approx 8 W
Operating Temperature	0 to 60 deg C
Storage Temperature	-40 to 85 deg C
Humidity	5 to 95% non-condensing
Mounting	Cabinet panel mount

Installation Guidelines

Ensure the control system is powered down before installing or removing the FTA to prevent electrical damage.
Mount the assembly securely within a clean, dry cabinet environment, ensuring adequate airflow to maintain operating temperatures below 60 deg C.
Use shielded cabling for all field inputs to minimize electromagnetic interference (EMI) and maintain signal integrity.
Verify correct polarity when connecting 2-wire or 3-wire transmitters to the terminal blocks.
Proper grounding of the assembly is essential for maintaining isolation and safety in hazardous-area applications.

FAQ

What is the primary function of the MU-GAIH13?
The MU-GAIH13 acts as a bridge between field-mounted smart transmitters and the Honeywell control system, providing isolated power to the transmitters and converting their 4-20 mA signals into a 1-5 VDC format for the DCS input modules.

Can this module be used for 3-wire transmitters?
Yes, the MU-GAIH13 is designed to support both 2-wire and 3-wire 4-20 mA smart transmitter configurations.

Is this module compatible with non-Honeywell systems?
The MU-GAIH13 is specifically engineered for integration with the Honeywell TPS distributed control system (DCS). Please consult your system documentation for compatibility with other platforms.
