1600071-001 Triconex TMR System Datasheet & Technical Manual

1600071-001 Triconex CBYY33001-2 Terminal Board Module

1600071-001 Triconex CBYY33001-2 Terminal Board Module

Availability: 10 left in stock

Triconex 1600071-001 Terminal Board Module The Triconex 1600071-001, also cataloged as the 1600071-001 Terminal Board Module, operates as a dedicated...

SKU: 1600071-001

Manufacturer: Triconex
Product No.: 1600071-001
Product Type: Terminal Board Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Triconex 1600071-001 Terminal Board Module

The Triconex 1600071-001, also cataloged as the 1600071-001 Terminal Board Module, operates as a dedicated hardware component for field signal interface execution within Triconex safety instrumented system networks. Configured to interface with 16 digital output points or up to 8 independent supervised frequency input channels, the hardware routes electrical inputs ranging from 0-24 VDC up to 20 kHz speed pulses directly into the triple redundant architecture. The component maintains a system response latency of less than 10 ms while continuously monitoring lines for structural field loop degradation.

Hardware Specifications

Parameter	Specification
Model	1600071-001 (CBYY33001-2)
Brand	Triconex (Schneider Electric)
Origin	United States
Weight	2.20 lbs (2.0 kg configuration base)
Dimensions	12.5 x 4.5 x 5.5 inches
Operating Temp	-40 to +70 deg C
Power Consumption	24 VDC +/-10%, less than or equal to 2.5 A
Input Signal Type	0-24 VDC Digital / Frequency Pulse (0-20 kHz)
Number of I/O Points	16 Digital Outputs / 8 Supervised Channels
Isolation Voltage	Greater than or equal to 1500 VDC channel-to-channel and field-to-backplane
Redundancy Matrix	Triple Modular Redundancy (TMR) 2oo3
Safety Compliance	IEC 61508 SIL 3 Certified

Triple Modular Redundancy (TMR) 2oo3 Architecture

The hardware utilizes isolated signal paths designed to pair with a triple modular redundancy (TMR) 2oo3 voting architecture, providing independent signal replication across three isolated internal links. Built-in self-test (BIST) diagnostic routines achieve a parameter diagnostic coverage of greater than or equal to 99%, isolating physical line faults and component drifts within 10 ms. The integrated 1500 VDC galvanic isolation field physically splits the input circuits from the internal bus structure, executing a continuous fail-safe state strategy that prevents external overvoltage conditions from reaching the logic solver processors.

Frequently Asked Questions

Q: What procedures govern the hot-swapping sequence of the 1600071-001 module?

A: The board architecture supports active online hot-swapping without risking system shutdown. Upon slot insertion, the internal supervisory layers perform diagnostic checks to verify firmware flash compatibility and align signal thresholds prior to integrating the new loop circuitry into the active TMR voting matrix.

Q: How does the interface process alternating digital output and speed frequency pulses?

A: The physical circuit paths are engineered to accept standard 0-24 VDC binary signals or high-frequency pulses from magnetic pickups and proximity probes up to 20 kHz, depending on the specific application termination parameters configured within the software environment.

Q: What are the isolation limitations between adjacent termination loops?

A: The board includes component barriers that provide a minimum of 1500 VDC channel-to-channel and field-to-backplane isolation. This layout prevents cross-talk and ensures that localized field grounding errors remain contained within a single loop terminal block.

Field Installation Guidelines

Mount the terminal board module into the assigned slot of the Tricon chassis framework, checking that the alignment tracks engage fully without forcing the backplane interface.
Terminate the 24 VDC operating power supply wires at the designated terminals, verifying that the source matches the required +/-10% voltage tolerance.
Fix all low-voltage sensor pulse lines or 24 VDC output conductors into the secure wire ports, checking that all terminal screws are locked down to avoid high-vibration loose contacts.
Route frequency cables from proximity probes or magnetic pickups through dedicated, isolated wire runs away from high-power AC distribution conduits.
Ground the terminal card shield connection directly to the low-impedance copper master instrument ground rail within the protective safety cabinet.
