19-Inch Rack Backplane SIL 3 Original | HIMA Z 6018

Availability: 99 left in stock

Product Overview The HIMA Z6018 functions as the structural and electronic backbone of the HIMA HiQuad Safety System. This backplane module hosts...

SKU: Z6018

Manufacturer: HIMA
Product No.: Z6018
Product Type: Backplane Modules
Product Origin: Germany
Payment:T/T, Western Union
Weight: 550g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The HIMA Z6018 functions as the structural and electronic backbone of the HIMA HiQuad Safety System. This backplane module hosts the central CPU and various I/O modules, facilitating high-speed data exchange and redundant power distribution across the system rack. Engineered for high-availability environments, the Z6018 ensures that safety-critical applications—such as Emergency Shutdown (ESD) and Burner Management Systems (BMS)—maintain deterministic performance even under fault conditions. We supply this module as 100% Brand New and Original, ensuring your safety loops comply with SIL 3 (IEC 61508/61511) requirements.

Technical Specifications

The Z6018 provides a robust interface for complex automation setups:

Category	Specification Details
Model Number	Z6018
Series Compatibility	HIMA HiQuad Safety Systems
Slot Capacity	Up to 16 Module Slots (Supports CPU + I/O)
Bus Architecture	Redundant Backplane Bus (Power & Communication)
Power Supply	24 VDC Nominal
Form Factor	19-Inch Rack Mount, 6U Height
Operating Temperature	–20°C to +60°C
Storage Temperature	–40°C to +85°C
Safety Certification	SIL 3 (IEC 61508), CE, TÜV
Weight	0.55 kg

Engineering Advantages

The Z6018 solves critical hardware integration challenges in industrial safety environments:

Redundant Communication Channels: The Z6018 incorporates a dual-bus architecture. This design prevents a single trace failure or connector fault from disabling the system, ensuring that the CPU retains control over I/O modules at all times.
High-Integrity Power Distribution: The backplane distributes redundant 24 VDC power across all slots. This eliminates the need for complex internal wiring harnesses and reduces potential points of failure within the cabinet.
Ruggedized Interference Shielding: To combat electromagnetic interference (EMI) common in power plants and chemical facilities, the Z6018 features integrated shielding. This protects the integrity of low-voltage safety signals as they traverse the bus.
Simplified Maintenance & Expansion: The standardized 19-inch 6U format allows for rapid installation into existing industrial enclosures. The modular slot design enables engineers to expand the system capacity by simply adding I/O modules without re-wiring the primary bus.

FAQs

Is the Z6018 compatible with HIMax series modules?

No. The Z6018 is specifically designed for the HIMA HiQuad series architecture. HIMax systems utilize different backplane standards. Always verify your system series before installation to ensure electrical and logical compatibility.

Does this backplane require a separate power module?

The Z6018 distributes 24 VDC power that is typically supplied by redundant external power units or HIMA-specific power supply modules located within the rack. It serves as the distribution layer rather than the power generator.

What is the recommended installation environment for SIL 3 compliance?

To maintain SIL 3 certification, you must install the Z6018 in an IP54-rated (or higher) enclosure if the environment contains conductive dust or high moisture. Furthermore, ensure the operating temperature remains within the –20°C to +60°C range to prevent thermal stress on the bus components.

How do I identify a bus fault on the Z6018?

The CPU modules residing on the Z6018 monitor the bus integrity. Any communication failure or power drop on the backplane will trigger a diagnostic alarm in the SILworX or ELOP II software, and status LEDs on the controller modules will indicate a bus error.
