Emerson KJ3002X1-BE1 12P0682X052 DeltaV M-Series Bus Extender Cable

Emerson KJ3002X1-BE1 12P0682X052 DeltaV M-Series Local Bus Right Extender Cable

Availability: 3 left in stock

DescriptionThe Emerson KJ3002X1-BE1 (12P0682X052) is a specialized Local Bus Right Extender Cable engineered for the DeltaV M-Series hardware platform. This...

SKU: KJ3002X1-BE1 12P0682X052

Manufacturer: Emerson
Product No.: KJ3002X1-BE1 12P0682X052
Product Type: Bus Extender Cable
Product Origin: USA
Payment:T/T, Western Union
Weight: 450g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Emerson KJ3002X1-BE1 (12P0682X052) is a specialized Local Bus Right Extender Cable engineered for the DeltaV M-Series hardware platform. This interconnect component facilitates the expansion of the DeltaV local bus across multiple I/O carrier rows, ensuring reliable high-speed data communication and power distribution between controllers and I/O modules. It is a critical component for scaling process automation systems in demanding environments, including oil refineries, power plants, and pharmaceutical manufacturing facilities.

Features

Bus Extension: Designed for right-hand local bus extension between DeltaV M-Series carriers.
Signal Integrity: Maintains high-speed logic signal transmission and 12 VDC local bus power continuity.
Environmental Durability: Rated for ISA-S71.04-1985 Class G3 harsh environment protection, preventing oxidation in corrosive atmospheres.
Industrial Construction: Features ruggedized high-density connectors designed to withstand thermal and mechanical stress within control cabinets.

Applications

This extender cable is used in DeltaV M-Series distributed control systems (DCS) to allow for flexible cabinet layouts and to bridge the local bus across multiple carrier rows, supporting system scalability and maintaining robust communication links.

Technical Specifications

Model	KJ3002X1-BE1 (12P0682X052)
Brand	Emerson
Series	DeltaV M-Series
Product Type	Local Bus Right Extender Cable
Bus Voltage	12 VDC
Operating Temperature	-40 to +70 deg C
Storage Temperature	-40 to +85 deg C
Relative Humidity	5 to 95 percent (Non-Condensing)
Airborne Contaminants	ISA-S71.04-1985 Class G3
Shock Resistance	10g 1/2 Sinewave for 11 msec
Vibration Resistance	1 mm Peak to Peak (5-16 Hz); 0.5g (16-150 Hz)

Installation Guidelines

Ensure the system power is completely disconnected before installing or removing the bus extender cable.
Align the high-density connectors carefully with the carrier interface to prevent pin damage.
Ensure the cable is routed away from high-EMI sources and high-voltage power cables to maintain signal integrity.
Verify that the cable is fully seated and secured according to DeltaV M-Series hardware installation standards.
Handle with standard ESD precautions to protect sensitive electronic components.

FAQ

What is the primary function of the KJ3002X1-BE1?

This cable serves as a bridge to extend the DeltaV local bus from one carrier to another on the right side, allowing for the physical expansion of I/O subsystems within a cabinet.

Is this cable compatible with non-M-Series systems?

No, this cable is specifically designed for the DeltaV M-Series hardware platform and its associated carrier architecture.
