TC-TBNH Honeywell 20-Pin Screw-Cage Clamp Terminal Block

Availability: 99 left in stock

Product Overview The Honeywell TC-TBNH serves as the primary physical interface for high-density field-side wiring within the Experion PKS Series...

SKU: TC-TBNH

Manufacturer: Honeywell
Product No.: TC-TBNH
Product Type: I/O Termination Assemblies
Product Origin: USA
Payment:T/T, Western Union
Weight: 140g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Honeywell TC-TBNH serves as the primary physical interface for high-density field-side wiring within the Experion PKS Series C I/O ecosystem. This 100% Brand New and Original 20-pin terminal block bridges the gap between field devices—such as transmitters and actuators—and the internal control electronics. By utilizing a modular plug-in architecture, the TC-TBNH allows technicians to replace active electronic modules without disturbing established field wiring. This design significantly reduces maintenance-induced downtime and eliminates the risk of wiring errors during hardware upgrades or repairs.

Technical Specifications

Parameter	Specification Details
Manufacturer	Honeywell
Model Number	TC-TBNH
Pin Count	20 Pins
Connection Type	Screw-cage clamp (Vibration Resistant)
Wire Gauge (Single)	14–22 AWG (0.64–1.63 mm)
Wire Gauge (Dual)	16–22 AWG (0.64–1.30 mm)
Contact Material	Plated High-Conductivity Copper Alloy
Insulation	UL-Rated Flame-Retardant Industrial Polymer
Interface	Plug-in header for Series C IOTA boards
Weight	0.14 kg
Environment	G3 Harsh Environment Compatible

Engineering Advantages

Gas-Tight Connection Integrity: The screw-cage clamp mechanism exerts constant, uniform pressure on the conductor. This mechanical force maintains a gas-tight seal that prevents oxidation and ensures a low-resistance electrical path, even in corrosive "Class G3" industrial atmospheres.
Streamlined Service Efficiency: The TC-TBNH enables "hot-swap" capabilities for I/O modules. Because the terminal block remains securely fixed to the Input Output Termination Assembly (IOTA) while the electronics are removed, it preserves the integrity of the loop wiring and prevents accidental short circuits during service.
Industrial Vibration Resistance: Designed for harsh environments, the mechanical clamping system withstands the low-frequency vibrations typical of pumping stations, turbine halls, and compressor decks. This prevents the terminal loosening that often causes intermittent signal failure in standard connectors.
High-Density Cabinet Optimization: The 20-pin configuration maximizes channel density for Series C IOTAs. This compact footprint allows engineers to pack more I/O points into a standard cabinet, reducing total infrastructure costs and footprint requirements for large-scale deployments.

FAQs

What is the difference between the TC-TBNH and the TC-TBCH?

The TC-TBNH is a 20-pin terminal block optimized for specific Series C IOTAs. In contrast, the TC-TBCH features 36 pins and targets high-density analog modules like the TC-IAH161. Always check your IOTA part number to ensure pin-count compatibility.

Can I use ferruled wires with this terminal block?

Yes. The screw-cage clamp accommodates both bare wire and ferruled conductors within the 14–22 AWG range. Ensure the ferrule length matches the insertion depth to guarantee a secure mechanical grip.

Does this block support G3-rated environments?

Yes. The high-conductivity copper alloy features specialized corrosion-resistant plating, making it suitable for sites requiring G3 conformal protection against hydrogen sulfide and other corrosive process gases.

Do I need specialized tools for installation?

No. A standard industrial terminal screwdriver operates the screw-cage clamps. The block itself plugs directly into the IOTA header and typically secures via integrated retention clips or screws depending on the specific IOTA model.
