Yokogawa S9757UV S9757UV CENTUM VP Power Supply Cable

Availability: 10 left in stock

Yokogawa S9757UV Power Supply Cable Configured for primary power feed to AEP7D-2 Primary Power Supply Bus Units in CENTUM VP...

SKU: S9757UV

Manufacturer: Yokogawa
Product No.: S9757UV
Product Type: Power Supply Cables
Product Origin: JAPAN
Payment:T/T, Western Union
Weight: 150g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Yokogawa S9757UV Power Supply Cable

Configured for primary power feed to AEP7D-2 Primary Power Supply Bus Units in CENTUM VP and ProSafe-RS systems, the Yokogawa S9757UV (S9757UV Power Supply Cable) provides direct physical/electrical execution for AC power delivery.

Hardware Specifications

Parameter	Specification
Model	S9757UV
Brand	Yokogawa
Origin	Japan
Weight	0.15 kg
Dimensions	300 x 330 x 60 mm
Operating Temp	-20 deg C to +80 deg C
Power Consumption	Passive physical power conductor assembly
Voltage Rating	220 V AC (50/60 Hz), up to 600 V AC/DC grade
Current Rating	Up to 15 A
Cable Length	2 m (6.56 ft)
Conductor Configuration	3-core, 14 AWG copper
Outer Cable Diameter	6 to 10 mm
Termination	Pre-terminated 3-pin plug (one end), unterminated strip-and-clamp (other end)

Process Control Power Lines & Insulation Integrity

The 3-core 14 AWG power cable routes 220 V AC line current directly into cabinet bus structures while preserving galvanic separation across internal system rails. Pin assignments enforce dedicated phase and return paths, assigning Black to Pin 4 (Phase), White to Pin 3 (Neutral), and Green to Pin 1 (Ground). Continuous insulation resistance and 600 V voltage withstand ratings prevent ground faults and electrical noise coupling across neighboring 4-20 mA HART loop protocol lines, thereby maintaining overall DCS loop stability.

Frequently Asked Questions

Q: What pinout configuration governs field connection of the pre-terminated plug end?

A: Technicians land the conductors using the pre-mapped assignments: Pin 4 connects Phase (Black), Pin 3 connects Neutral (White), and Pin 1 connects Earth Ground (Green).

Q: How does the unterminated cable end facilitate custom cabinet integration?

A: The unterminated end features stripped lead ends that allow field personnel to wire directly into custom terminal blocks, circuit breakers, or field distribution bus bars.

Q: What physical bending restrictions apply during cable routing in power distribution panels?

A: Wiring crews must enforce minimum bend radius standards based on the overall 6 to 10 mm cable jacket diameter to prevent conductor fatigue and preserve inner insulation integrity.

Field Installation Guidelines

Field engineers must route the S9757UV cable through dedicated AC power troughs, separating power feeds from sensitive analog I/O wiring. Technicians connect the pre-terminated 3-pin plug directly into the mating inlet of the AEP7D-2 bus unit, locking the connection securely. Installers strip and land the unterminated end into designated terminal clamps, torqueing screw terminals to standard specification to prevent high-resistance connection points. Finally, verify proper earth continuity on the Green ground conductor before energizing the 220 V AC circuit.
