140NOE77101 Quantum PLC | 10/100Mbps Ethernet Interface

Availability: 94 left in stock

Product Overview The 140NOE77101 (Part Number: 140NOE77101) is a robust Ethernet communication interface module designed for the Schneider Electric Modicon Quantum automation...

SKU: 140NOE77101

Manufacturer: Schneider
Product No.: 140NOE77101
Product Type: Communication Interface Module
Product Origin: France
Payment:T/T, Western Union
Weight: 345g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The 140NOE77101 (Part Number: 140NOE77101) is a robust Ethernet communication interface module designed for the Schneider Electric Modicon Quantum automation platform. This module serves as the primary gateway for connecting Quantum PLCs to standard Ethernet TCP/IP networks, facilitating high-speed data exchange for peer-to-peer communication, HMI/SCADA integration, and remote programming.

Engineered for reliability in large-scale industrial environments, the 140NOE77101 (Model: 140NOE77101) features a built-in HTTP web server. This allows engineers to perform remote diagnostics, view rack configurations, and monitor real-time Ethernet statistics through a standard web browser without requiring proprietary software. The module also supports Hot Standby (HSBY) architectures, ensuring communication continuity in mission-critical high-availability systems.

Detailed Technical Specifications

The 140NOE77101 provides advanced networking capabilities with the following technical parameters:

Manufacturer: Schneider Electric
Product Range: Modicon Quantum
Model Number: 140NOE77101
Communication Port: 1 × RJ45 connector
Transmission Rate: 10/100 Mbps (Auto-sensing, Full/Half Duplex)
Bus Protocol: Ethernet TCP/IP
Services Supported: Modbus TCP (Client/Server), HTTP, BOOTP/DHCP, SNMP, FTP
Web Server Functions: Data Editor, Rack Viewer, Ethernet Statistics, Diagnostics
Address Configuration: Via software (Unity Pro / EcoStruxure) or hardware MAC address
Memory Type: Flash memory for user-driven firmware upgrades
Current Consumption: 750 mA maximum from the Quantum backplane bus
Diagnostics (Module): LEDs for RUN, ERR, and COL (Collision)
Diagnostics (Network): LEDs for ACT (Activity), LINK, and 100MB status
Redundancy Support: Compatible with Quantum Hot Standby (HSBY) systems
Net Weight: 0.345 kg (0.76 lbs)
