80097-01 Bently Nevada Six-Channel Thermocouple/RTD Monitor

80097-01 Bently Nevada Six-Channel Thermocouple/RTD Monitor

Availability: 10 left in stock

Product Overview The Bently Nevada 80097-01 is a high-precision Six-Channel Temperature Monitoring Module specifically designed for the 3300 Series machinery protection racks. This module provides continuous,...

SKU: 80097-01

Manufacturer: Bently Nevada
Product No.: 80097-01
Product Type: Temperature Monitors
Product Origin: USA
Payment:T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Bently Nevada 80097-01 is a high-precision Six-Channel Temperature Monitoring Module specifically designed for the 3300 Series machinery protection racks. This module provides continuous, real-time thermal oversight of critical rotating assets by processing signals from Resistance Temperature Detectors (RTDs) and thermocouples. It identifies abnormal temperature rises in bearings, casings, and motor windings before mechanical failure occurs. By integrating directly into the 3300 system backplane, the 80097-01 delivers localized alarm logic and scalable analog outputs, forming a vital component of proactive condition monitoring and predictive maintenance strategies.

Technical Specifications

The 80097-01 utilizes advanced signal conditioning to maintain data accuracy across a wide measurement spectrum.

Feature	Specification
Model Number	80097-01
Input Channels	6 Independent Channels
Sensor Compatibility	RTDs (100 $\Omega$ Platinum) and Thermocouples (Type J, K, T, etc.)
Measurement Range	–200 °C to +850 °C (Sensor dependent)
Alarm Setpoints	Independent Alert and Danger levels per channel
Output Signals	Scaled Analog Voltage / Configurable Relays
Power Requirement	+24 VDC (Backplane supplied)
Operating Temp	–40 °C to +85 °C
Mounting	3300 Series Rack-mount
Condition	100% Brand New and Original

Engineering Advantages

Simultaneous Multi-Point Monitoring: The module tracks six independent temperature zones through a single rack slot. This high-density architecture allows engineers to monitor multiple bearing points or motor phases simultaneously, reducing the total hardware footprint required for comprehensive machinery protection.
Universal Sensor Interfacing: The 80097-01 accepts both RTD and thermocouple inputs. This flexibility eliminates the need for separate hardware modules when a machine utilizes different sensor types for casing and bearing measurements, simplifying spare parts inventory.
Deterministic Alarm Logic: Every channel features dedicated Alert and Danger setpoints. When temperatures breach these thresholds, the module triggers integrated relays or system alarms instantly. This localized hardware-level logic ensures that protection actions occur independently of external software, maximizing system reliability.
Ruggedized Signal Integrity: Bently Nevada builds the 80097-01 to thrive in harsh industrial environments. The circuitry rejects electromagnetic interference (EMI) and maintains precision even in the presence of the high-vibration and humidity levels typical of steam turbine halls and compressor stations.

FAQs

Q: Is the Bently Nevada 80097-01 supplied as 100% Brand New?

A: Yes. We supply only 100% Brand New and Original Bently Nevada hardware in factory-sealed packaging. Every module includes a 12-month factory warranty to guarantee the safety of your critical rotating equipment.

Q: Can I mix RTDs and Thermocouples on the same 80097-01 module?

A: While the module hardware supports both types, the configuration typically requires specific input terminal blocks or jumpers to match the sensor characteristics. Always refer to your specific 3300 rack wiring diagram to ensure proper impedance matching for the selected sensors.

Q: How does this module assist in predictive maintenance?

A: The 80097-01 provides scaled analog outputs that interface with Data Acquisition Systems (DAQ). By tracking historical temperature trends, maintenance teams can identify gradual thermal degradation in bearings, allowing for scheduled interventions rather than emergency shutdowns.

Q: Does the module require manual calibration during installation?

A: Bently Nevada modules come factory-calibrated. However, upon installation into a 3300 rack, you must configure the zero and span settings to match your specific sensor range and required alarm setpoints using the system's calibration procedures.
