GE IC200MDL331 VersaMax Isolated AC Output Original

Availability: 10 left in stock

Product Overview The IC200MDL331 provides eight isolated channels of discrete AC output for the VersaMax PLC platform. Operating at a nominal 120VAC,...

SKU: IC200MDL331

Manufacturer: GE Fanuc
Product No.: IC200MDL331
Product Type: Isolated Output Technology
Product Origin: USA
Payment:T/T, Western Union
Weight: 700g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The IC200MDL331 provides eight isolated channels of discrete AC output for the VersaMax PLC platform. Operating at a nominal 120VAC, each channel delivers up to 2.0 Amperes of current, making it ideal for driving heavy-duty industrial solenoids, motor starters, and large indicator lamps. We offer this module as 100% Brand New and Original, ensuring your control system operates with factory-certified switching precision and robust channel isolation.

Technical Specifications

Feature	Details
Manufacturer	GE Fanuc (Emerson Automation)
Output Type	Discrete AC (Isolated)
Number of Channels	8 (Individually Isolated)
Operating Voltage Range	85 to 132 VAC (47–63 Hz)
Current per Channel	2.0 A (Maximum) / 0.5 A (Minimum)
Maximum Inrush Current	20 Amps
Output Leakage Current	< 2 mA at 132 VAC
Backplane Current (5V)	85 mA (Maximum)
Response Time	½ Cycle (Typical)
Internal Protection	Integrated Snubber and MOV for each output
Isolation Rating	1500 VAC (1 minute) Channel-to-Channel / Logic

Engineering Advantages

Individual Channel Isolation: The IC200MDL331 isolates each of the eight outputs individually. This architecture allows the module to switch different AC phases or separate power sources within a single module, eliminating the need for multiple interposing relays or additional hardware.
Heavy-Duty Load Capacity: While standard PLC outputs often struggle with high-current demands, this module supports 2.0 Amperes per point. It directly controls large inductive loads, reducing cabinet complexity and wiring costs.
Integrated Surge Suppression: Every output contains a built-in Snubber circuit and Metal Oxide Varistor (MOV). These components absorb transient voltage spikes generated by inductive switching, protecting both the module’s internal circuitry and the connected field devices.
Optical Logic Isolation: Optical couplers separate the field-side AC voltage from the low-voltage PLC backplane logic. This provides up to 1500 VAC of protection, ensuring that field faults do not propagate to the CPU or other sensitive modules.
Real-Time Diagnostic LEDs: Individual channel LEDs provide immediate visual confirmation of output status. An additional "OK" LED monitors module health, significantly accelerating troubleshooting during commissioning or maintenance cycles.

FAQs

Can I use the IC200MDL331 with DC loads?

No. This module utilizes triac-based switching designed specifically for AC circuits (85-132 VAC). Attempting to switch DC loads will result in the output failing to turn off once energized.
What is the significance of the 0.5A minimum load requirement?

Triacs require a minimum holding current to stay in the "ON" state. If your load (such as a small LED indicator) draws less than 0.5A, the output may flicker or fail to latch. In such cases, you must install a parallel bleeder resistor to increase the current draw.
Does this module require an external power supply?

The module draws 85mA from the backplane for logic operation, but the power used to drive the loads must come from an external AC source (85-132 VAC) wired to the isolated terminals.
How does individual isolation help in a multi-phase system?

Because each channel is isolated from the others, you can wire Channel 1 to Phase A and Channel 2 to Phase B without causing a short circuit. This is highly effective for controlling motors or devices across different power legs.
