YOKOGAWA F3XC08-0C Digital Output Module

Configured for discrete signal switching in FA-M3 PLC platforms, the YOKOGAWA F3XC08-0C (F3XC080C Digital Output Module) provides direct physical/electrical execution of 8-channel relay control sequences.

Suffix Breakdown & Model Matrix

F3XC08: Base model identifier for 8-channel relay output functionality.
-0C: Configuration code indicating relay contact type and interface standards for the FA-M3 base unit backplane.

Hardware Specifications

Parameter	Specification
Model	F3XC08-0C
Brand	YOKOGAWA
Origin	Japan
Weight	0.45 kg
Dimensions	120 × 90 × 40 mm
Operating Temp	-10 deg C to +55 deg C
Power Consumption	5 V DC, ~300 mA
Output Channels	8 (Form A Relay)
Rated Load	24 V DC / 120 V AC
Max Load Current	2 A (Resistive)
Response Time	<= 10 ms

PLC Control & Deterministic Network Attributes

The F3XC08-0C executes switching operations across FA-M3 backplane architectures. To maintain system stability, the module performs deterministic command processing, ensuring that relay state transitions remain within the defined latency constraints of the PLC backplane bus. The module incorporates firmware-level monitoring for communication integrity, preventing indeterminate states during bus faults. In environments requiring multi-node coordination, the module's I/O density scaling allows for expansion of discrete control points without exceeding the backplane power budget or communication bandwidth.

Frequently Asked Questions

Q: Does this module support hot-swapping?

A: No. The F3XC08-0C requires the PLC base unit power to be disconnected before module extraction or insertion to prevent damage to backplane communication pins or relay contact terminals.

Q: How should inductive loads be managed with this relay module?

A: While the module includes surge suppression, external flyback diodes for DC loads or RC snubbers for AC loads are recommended to extend the mechanical contact life of the internal relays.

Q: What is the maximum switching frequency of the relay contacts?

A: The physical response time is <= 10 ms. Exceeding recommended switching cycles leads to premature relay contact degradation; avoid high-duty cycling for rapid-action applications.

Field Installation Guidelines

Mounting: Secure the module to the FA-M3 base unit. Tighten mounting screws to provide electrical continuity for the chassis ground.
Wiring: Maintain separation between relay output load wiring (high voltage/current) and low-voltage communication cabling to prevent inductive coupling.
Grounding: Connect the FA-M3 base unit to a low-impedance earth point. Use shielded cables for long-distance runs to minimize noise pick-up on output lines.
Thermal Management: Ensure at least 50 mm of clearance above and below the module to facilitate convective cooling, particularly when operating multiple channels at maximum load current.
