8C-PAIMA1 Honeywell 8-Channel Analog Input Module

8C-PAIMA1 Honeywell 8-Channel Analog Input Module | New & Original Stock

Availability: 99 left in stock

Honeywell 8C-PAIMA1 Experion PKS Series 8 The Honeywell 8C-PAIMA1 serves as the primary 8C-PAIMA1 Analog Input Module utilized to execute...

SKU: 8C-PAIMAI

Manufacturer: Honeywell
Product No.: 8C-PAIMAI
Product Type: Analog Input Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Honeywell 8C-PAIMA1 Experion PKS Series 8

The Honeywell 8C-PAIMA1 serves as the primary 8C-PAIMA1 Analog Input Module utilized to execute high-precision data acquisition across Experion PKS Series 8 C300 platforms.

Hardware Specifications

Parameter	Specification
Model	8C-PAIMA1
Brand	Honeywell
Origin	United States
Weight	0.3 kg
Dimensions	5.1 cm x 26.7 cm x 17.8 cm
Operating Temp	-40 to +70 deg C
Power Consumption	Backplane powered via Series 8 carrier
Input Channels	8 Isolated Analog Channels
Signal Configurations	4-20 mA current loop, 1-5 VDC voltage, Resistance
Protocol Support	Native HART (Highway Addressable Remote Transducer)
A/D Resolution	16-bit analog-to-digital conversion
Isolation Profile	Full channel-to-channel and channel-to-logic galvanic isolation
Safety Compliance	CE, TUV, UL508, CSA, IEC 61508 (SIL 2/3 capable)

Process Control and DCS Instrumentation

The module architecture incorporates a 4-20 mA HART loop protocol engine across 8 isolated channels, enabling simultaneous extraction of primary process variables and secondary digital diagnostics from smart field instruments. Structural channel-to-channel isolation prevents ground loop current transmission and cross-talk interference, protecting the internal 16-bit analog-to-digital conversion matrix. An onboard microprocessor executes real-time signal conditioning and digital filtering, maintaining a stable data interface within a hardened operating window of -40 to +70 deg C.

Frequently Asked Questions

Q: How does the 8C-PAIMA1 manage secondary variables from smart transmitters?

A: The onboard microprocessor features integrated HART modems per channel. This configuration executes native digital modulation pass-through, allowing the C300 controller to continuously poll secondary variables and status registers directly over the analog 4-20 mA signal wiring.

Q: What are the electrical isolation limits between individual channels on this module?

A: The module is built with complete galvanic channel-to-channel and channel-to-logic isolation. This physical separation prevents localized voltage spikes or ground potential differences on one field loop from propagating to adjacent channels or degrading the system backplane.

Q: Is this analog input module approved for use in safety-instrumented systems?

A: Yes, the 8C-PAIMA1 is compliant with IEC 61508 standards and holds TÜV certification, designating the module as SIL 2 and SIL 3 capable for deployment in high-integrity process safety functions.

Field Installation Guidelines

Module Insertion and Retention: Align the 8C-PAIMA1 module along the chassis guides of the Series 8 I/O Termination Assembly (IOTA). Press firmly until the mechanical locking latches engage to ensure positive electrical contact with the backplane connectors.
Shield Grounding Matrix: Connect all smart transmitter twisted-pair shielding drain wires directly to the master copper instrumentation ground bar within the enclosure. Do not ground the shields at the field instrument side to avoid circulating earth currents.
Signal Cable Separation: Route the low-voltage 4-20 mA/1-5 VDC input signal cables inside distinct wire ducts separate from heavy AC power lines, variable frequency drives, and inductive load switching circuits to prevent electromagnetic noise coupling.
