ABC11D Yokogawa CENTUM VP Dual-Redundant Bus Converter

Availability: 99 left in stock

Yokogawa ABC11D Dual-Redundant Bus Converter The Yokogawa ABC11D, also cataloged as the ABC11D Dual-Redundant Bus Converter, operates as a dedicated...

SKU: ABC11D

Manufacturer: Yokogawa
Product No.: ABC11D
Product Type: Dual-Redundant Bus Converters
Product Origin: JAPAN
Payment:T/T, Western Union
Weight: 1500g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Yokogawa ABC11D Dual-Redundant Bus Converter

The Yokogawa ABC11D, also cataloged as the ABC11D Dual-Redundant Bus Converter, operates as a dedicated hardware component for bridging HIS stations on V-net to other system buses within Yokogawa CENTUM VP / CS DCS systems. The network interface module maintains deterministic data transmission rates up to 100 Mbps while managing automatic switchover routines across active redundant communication pathways.

Hardware Specifications

Parameter	Specification
Model	ABC11D
Brand	Yokogawa
Origin	Japan
Weight	1.5-4.2 kg depending on version
Dimensions	482 mm x 310 mm x 133 mm
Operating Temp	0-50 deg C
Power Consumption	~110 W typical (AC)
Power Supply Options	100-120 VAC, 220-240 VAC (50/60 Hz), or 24 VDC
Data Transmission Rate	Up to 10 Mbps (fieldbus), 10-100 Mbps (control network)
Protocols Supported	FOUNDATION Fieldbus H1, Profibus PA, HART passthrough
Isolation	Channel-to-channel galvanic isolation
Failover Time	Automatic switchover within one bus cycle
Mounting	Standard 19-inch rack or compact rack mount

Process Control & DCS Instrumentation Integration

The ABC11D integrates a dedicated 4-20 mA HART loop protocol architecture alongside foundational FOUNDATION Fieldbus / Profibus PA connectivity parameters to establish consistent digital device communication links. The internal circuitry implements complete channel-to-channel isolation barriers to block high-frequency electromagnetic interference and intercept circulating ground loop currents before they reach the control nodes. If a data path interruption occurs, the internal diagnostic watchdog triggers an automatic, hardware-driven failover sequence that completes within a single bus cycle, preserving deterministic cycle times across the active control network segment without dropping field data packets.

Frequently Asked Questions

Q: What specific failure mechanisms trigger the dual-redundant bus switchover routine?

A: The onboard self-diagnostics continuously monitor transmission error rates, signal attenuation thresholds, and frame collisions. If physical layer degradation or bus power drops below the nominal operating limit, the converter isolates the faulted channel and transfers traffic to the redundant line within one bus cycle.

Q: Can maintenance personnel execute hot-swap module replacements on live control networks?

A: Yes, certain power and bus interface modules within the system framework permit hot-swap replacement during active operations. Technicians must replace the secondary module only while the primary module maintains steady-state communication on the parallel bus path.

Q: How does the ABC11D route intelligent instrumentation diagnostics back to the asset manager?

A: The converter contains dedicated hardware-level HART passthrough capability. It reads the secondary and tertiary digital variables embedded within the analogue loop signals and encapsulates them into the high-speed control network protocol without disturbing primary process variables.

Field Installation Guidelines

Mount the ABC11D converter assembly inside a standard 19-inch instrumentation rack enclosure using approved mechanical hardware. Tighten all retention screws to specified torque ratings to ensure rigid positioning and prevent vibration-induced contact resistance at the backplane interface terminals.

Route the incoming dual-redundant communication cables through separate, isolated wire ducts to minimize the risk of simultaneous physical damage to both channels. When landing the network lines, strip the insulation carefully to expose the grounding shield, and connect the shield drains directly to the system instrument earth bus bar rather than the local enclosure structural frame. Maintain separate wire pathways for the high-voltage AC mains lines, keeping them physically isolated from the low-voltage fieldbus lines to maximize overall signal-to-noise ratios.
