Product Overview

The Yokogawa ATD5S-00 serves as a high-performance pressure clamp terminal block designed specifically for seamless integration within Yokogawa’s Distributed Control Systems (DCS) and Programmable Logic Controllers (PLC). This module eliminates the need for traditional screw-based wiring, utilizing a robust spring-pressure mechanism that guarantees constant contact force. Engineers deploy the ATD5S-00 to streamline cabinet assembly, reduce wiring errors, and ensure long-term signal integrity in high-vibration industrial environments.

Condition: 100% Brand New Original Equipment.

Technical Specifications

The following table outlines the critical electrical and physical parameters for the ATD5S-00:

Parameter	Specification
Rated Voltage	250 V AC/DC
Rated Current	5 A per channel
Clamping Type	Spring Pressure (Screwless)
Wire Compatibility	0.2 mm² to 2.5 mm² (Solid/Stranded)
Dielectric Strength	2000 V AC for 1 minute
Insulation Resistance	≥ 500 MΩ @ 100 V DC
Operating Temperature	-20°C to +70°C
Dimensions (W x H x D)	32.6 mm x 114 mm x 60.5 mm
Mounting Type	Standard DIN Rail

Engineering Advantages

Vibration-Proof Connectivity: Unlike traditional screw terminals that loosen under thermal cycling or mechanical vibration, the ATD5S-00 spring clamp exerts continuous pressure on the conductor. This maintains a gas-tight connection and prevents intermittent signal loss.
Rapid Installation Workflow: The tool-free entry design allows technicians to insert stripped wires directly into the clamp. This reduces labor hours during large-scale cabinet builds and minimizes the risk of over-tightening or stripping screw threads.
High-Density Cabinet Optimization: With a slim 32.6 mm width profile, the ATD5S-00 maximizes rail space. This compact footprint enables higher I/O density within standard enclosures without sacrificing heat dissipation or accessibility.
Enhanced Safety Standards: The industrial-grade insulation material provides a 2000V dielectric strength, protecting sensitive upstream PLC/DCS electronics from voltage surges and cross-channel interference.

FAQs

Q: Does the ATD5S-00 require specialized ferrules for stranded wire?

A: No. The spring pressure mechanism accepts both solid and stranded wires (0.2 to 2.5 mm²) directly. However, using insulated ferrules can further enhance wire organization and prevent fraying during repeated maintenance cycles.

Q: How does the ATD5S-00 handle high-temperature cabinet environments?

A: Yokogawa constructs the ATD5S-00 using high-dielectric, heat-resistant polymers rated for operation up to +70°C. This ensures the housing maintains structural integrity even when installed near high-heat components like power supplies or frequency drives.

Q: Is this model compatible with third-party PLC systems?

A: While designed for Yokogawa ecosystems, the ATD5S-00 functions as a standard DIN-rail mounted pressure clamp terminal. It can interface with any system requiring 250V/5A signal termination, provided the physical footprint fits your layout requirements.

Q: What is the primary difference between the ATD5S terminal block and the ATD5S I/O module?

A: The ATD5S-00 listed here is the physical terminal interface (Pressure Clamp). While some digital I/O modules share a similar nomenclature, this specific unit functions as the connection point for field wiring, ensuring secure electrical paths to the processing hardware.
