HIMA F 6202 HIQuad Safety Series Datasheet & Technical Manual

Availability: 99 left in stock

HIMA F6202 HIMax/HIQuad Safety Series The HIMA F6202, also cataloged as the F6202 Safety-related Controller Module (CPU), serves as the...

SKU: F6202

Manufacturer: HIMA
Product No.: F6202
Product Type: CPU Processors
Product Origin: Germany
Payment:T/T, Western Union
Weight: 1361g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

HIMA F6202 HIMax/HIQuad Safety Series

The HIMA F6202, also cataloged as the F6202 Safety-related Controller Module (CPU), serves as the primary F6202 Safety-related Controller Module (CPU) utilized to execute safety logic, process inputs, and control outputs across Safety Instrumented Systems (SIS) platforms.

Hardware Specifications

Parameter	Specification
Model	F6202 (Part No. 981620202)
Brand	HIMA
Origin	Germany
Weight	3.00 lbs
Dimensions	216 x 130 x 30 mm
Operating Temp	0 to +60 deg C
Power Consumption	3 W
System Compatibility	HIMA HIQuad safety system
Safety Certification	SIL 3 (IEC 61508)
Redundancy Support	1oo2, 2oo3 configurations
Diagnostics	Built-in self-test, continuous fault monitoring
Programming Tool	HIMA ELOP II Factory
Communication Interface	Proprietary HIMA system bus
Supply Voltage	5 VDC via backplane
Storage Temp	-40 to +85 deg C
Humidity Tolerance	5-95% RH, non-condensing
Protection Class	IP20 (rack mounted)
Certifications	IEC 60068-2 compliant

High Reliability Safety Control (SIS)

The module architecture incorporates SIL 3 certification parameters to ensure structural code and signal execution viability. The circuit architecture uses internal triple modular redundancy (TMR) 2oo3 architecture pathways to continuously validate field command processing against localized hardware discrepancies. Complete galvanic isolation across potential-free relay interfaces minimizes circuit cross-talk, permitting direct fail-safe state execution at the physical layer when sensor or internal monitoring limits are breached.

Frequently Asked Questions

Q: Can the F6202 module be exchanged while the overall safety controller remains energized?

A: Yes, the hardware design is hot-swappable, which allows field technicians to replace the module during live operations without disrupting system uptime or halting safety logic execution.

Q: How is the physical redundancy voting system configured for critical applications?

A: The processor natively supports both dual 1oo2 and triple modular 2oo3 configurations, allowing the application engineers to set specific voting tolerances via the HIMA ELOP II Factory software tool.

Field Installation Guidelines

Insert the module vertically into the allocated chassis slot guide rails, ensuring the integrated connectors on the PC board line up cleanly with the backplane receiving pins. Tighten all integrated faceplate retention fasteners to ground the front bracket and lock the module assembly against mechanical vibration stresses. Route all external communication bus wiring inside closed layout trays completely isolated from any high-current parallel AC electricity paths. Maintain free vertical spacing clearances across the enclosure grid columns to sustain uninhibited convection currents for heat dissipation through the IP20 chassis.
