Honeywell 51306920-176 FC-TUIO11 Universal Analog I/O

Availability: 99 left in stock

Product Overview The Honeywell FC-TUIO11 (Part Number: 51306920-176) serves as the most versatile interface within the Safety Manager SC (S300 IOTA) ecosystem. This Universal Safety...

SKU: FC-TUIO11

Manufacturer: Honeywell
Product No.: FC-TUIO11
Product Type: Safety Manager SC
Product Origin: USA
Payment:T/T, Western Union
Weight: 350g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Honeywell FC-TUIO11 (Part Number: 51306920-176) serves as the most versatile interface within the Safety Manager SC (S300 IOTA) ecosystem. This Universal Safety I/O Module executes high-precision signal processing for both analog inputs and outputs on a single hardware platform. By supporting configurable 4–20 mA and 0–10 V signals, it streamlines the integration of pressure transmitters, flow meters, and control valve actuators into safety-instrumented functions. We supply this unit as 100% Brand New and Original, featuring the latest Rev D engineering improvements for mission-critical SIL3 applications.

Technical Specifications

Attribute	Specification Value
Model Number	FC-TUIO11 (51306920-176)
Channel Capacity	Configurable Analog I/O (Typically 8 Channels)
Signal Input Range	0–20 mA, 4–20 mA, or 0–10 V
Signal Output Range	4–20 mA
Safety Certification	SIL3 (IEC 61508 Compliant)
Accuracy	±0.1% of span (Typical)
Operating Temperature	–40°C to +85°C
Isolation	Channel-to-Channel & Channel-to-System Bus
Mounting	S300 IOTA Termination Assembly
Weight	0.2 kg (Net) / 0.5 kg (Shipping)
Dimensions	3.2 cm x 12.7 cm x 12.7 cm

Engineering Advantages

Universal Configuration Flexibility: The FC-TUIO11 eliminates the need for stocking multiple dedicated input and output cards. Engineers configure each channel via software to act as either an input or an output, significantly reducing spare parts inventory and simplifying site-wide standardization.
SIL3-Rated Safety Integrity: Every channel undergoes rigorous self-diagnostics to meet SIL3 standards. The module detects internal component drift and external loop faults instantly, ensuring that safety-critical actuators—such as Emergency Shutdown Valves (ESV)—receive accurate commands during hazardous process excursions.
Galvanic Signal Isolation: Robust optical and electrical isolation barriers protect the system backplane from field-side transients. This architecture prevents a short circuit in one field transmitter from cascading through the rest of the Safety Manager SC rack.
Extreme Climate Resilience: Engineered with industrial-grade components, the FC-TUIO11 operates in temperatures ranging from –40°C to +85°C. This capability allows for direct installation in remote instrument enclosures (RIE) without the need for supplemental air conditioning.
Hot-Swap Maintainability: The module supports full hot-swap functionality. Maintenance personnel can replace a module without de-energizing the IOTA or interrupting the logic execution of adjacent safety loops, maintaining 24/7 operational continuity.

FAQs

How does the "Universal" feature benefit my installation?

Unlike fixed-function cards, the FC-TUIO11 allows you to mix sensors (Inputs) and actuators (Outputs) on the same module. This flexibility is ideal for small remote stations where you need a limited number of both signals but only have one available slot.
Does this module require a specific revision of the Safety Manager SC?

The FC-TUIO11 Rev D requires compatible Safety Manager SC firmware. Always verify your current software revision in the Safety Manager Builder to ensure full access to the module's diagnostic and configuration features.
What is the significance of the 51306920-176 part number?

This is the unique Honeywell identifier for the FC-TUIO11 assembly. It ensures you are receiving the correct hardware specified for the S300 IOTA subsystem, complete with the appropriate safety certifications.
Is this module 100% Brand New?

Yes. We only supply 100% Brand New and Original Honeywell modules. Each unit arrives in its original factory packaging with a clear Rev D designation, ensuring the latest manufacturing standards.
