8C-PDISA1 Honeywell Series 8 Datasheet & Technical Manual

Honeywell 8C-PDISA1 Experion PKS Series 8 Digital Input Module

Honeywell 8C-PDISA1 Experion PKS Series 8 Digital Input Module

Availability: 99 left in stock

The Honeywell 8C-PDISA1, also cataloged as the 8C-PDISA1 Digital Input Module, operates as a dedicated hardware component for Sequence of...

SKU: 8C-PDISA1

Manufacturer: Honeywell
Product No.: 8C-PDISA1
Product Type: Digital I/O Cards
Product Origin: USA
Payment:T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

The Honeywell 8C-PDISA1, also cataloged as the 8C-PDISA1 Digital Input Module, operates as a dedicated hardware component for Sequence of Events (SOE) monitoring within Experion PKS Series 8 / C300 Controller networks. The module processes state changes across 32 discrete channels, stamping transition data directly at the hardware layer with a 1 ms resolution limit. This physical architecture records precise temporal transition sequences independently of the main controller scanning sweep cycles.

Hardware Specifications

Parameter	Specification
Model	8C-PDISA1
Brand	Honeywell
Origin	USA
Weight	0.3 kg
Dimensions	5.1 cm x 26.7 cm x 17.8 cm
Operating Temp	-40 to +70 deg C
Power Consumption	4.2 Watts (Typical)
I/O Type	Digital Input (DI) with Sequence of Events (SOE)
Channel Density	32 Optically Isolated Channels
Input Voltage	24 VDC (Nominal)
Timestamp Resolution	1 ms
Environmental Rating	Conformal Coated (G3 rating)
Signal Isolation	Galvanic/Optical Isolation
Operating Logic	Open and Closed contact logic
Mounting Base	Series 8 I/O Termination Assembly (IOTA)

Process Control and DCS Instrumentation Features

The discrete input channels communicate field states across dedicated optical isolation paths, establishing independent channel-to-channel isolation parameters to suppress ground loops. Field loops interface directly through the 4-20 mA HART loop protocol cabinet architecture, where this module handles the high-density binary tracking. The module hardware maintains precise filtering algorithms for contact debouncing, while the internal logic card handles local voltage monitoring. This digital front-end runs in sync with cold junction compensation (CJC) and analog input sub-buses on adjacent Series 8 hardware.

Frequently Asked Questions

Q: How does the module execute hot-swap replacement under active system power?

A: The hardware architecture allows live insertion and extraction on the Series 8 I/O Termination Assembly (IOTA) without interrupting the backplane bus traffic or forcing the C300 controller into a fault condition.

Q: What is the benefit of the integrated G3-rated conformal coating on this unit?

A: The G3 coating provides chemical and moisture protection across the internal circuit boards, preventing trace degradation from airborne contaminants and high humidity levels in unconditioned remote instrument enclosures.

Field Installation Guidelines

IOTA Engagement: Align the module pins with the corresponding sockets on the Series 8 I/O Termination Assembly (IOTA). Push the hardware perpendicularly until the locking side-latches fully engage the mounting plate.
Shield Wire Grounding: Land the field cable outer shields exclusively at the designated instrumentation earth bar inside the marshalling cabinet enclosure. Avoid grounding the shield at the field switch housing to eliminate parasitic currents.
Signal Cable Segregation: Route the 24 VDC discrete input field wiring through dedicated wireways separate from parallel high-voltage AC motor control lines or heavy distribution cabling to minimize inductive noise coupling.
