PowerFlex SCR Rectifier Control Board

PowerFlex SCR Rectifier Control Board | 80190-380-01-R

Availability: 20 left in stock

Product Overview The Allen Bradley 80190-380-01-R serves as a specialized rectifier controller and digital input module interface board designed for...

SKU: 80190-380-01-R

Manufacturer: Allen Bradley
Product No.: 80190-380-01-R
Product Type: Rectifier Control Boards
Product Origin: USA
Payment:T/T, Western Union
Weight: 320g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Allen Bradley 80190-380-01-R serves as a specialized rectifier controller and digital input module interface board designed for the converter section of PowerFlex 7000 medium voltage variable frequency drives. This printed circuit board manages the input rectifying stage, interfacing directly with the system control architecture to regulate the incoming three-phase AC power as it converts to DC link voltage. The board features an integrated 8-channel digital input module that processes 24V DC feedback loops from peripheral auxiliary contacts, safety interlocking circuits, and rectifier status points. We supply this product exclusively as a 100% brand-new, original unit to ensure factory-calibrated signal timing and complete system compatibility within heavy industrial power enclosures.

Technical Specifications

Parameter	Specification
Manufacturer	Allen Bradley / Rockwell Automation
Part Number	80190-380-01-R
PCB Base Number	80190-378-51/12
Condition	100% Brand New Original
Hardware Classification	Rectifier Controller Board / Digital Input Module
Input Signal Voltage	24 Volts DC (Nominal)
Number of Channels	8 Independent Input Channels
Current Consumption	5 milliamps per channel
Board Physical Footprint	25.2cm x 19cm x 2.7cm
Net Weight	0.32 kg (0.51 lbs)
Country of Origin	United States
System Compatibility	PowerFlex 7000 Medium Voltage Drive Infrastructure
Environmental Target	Industrial-grade, vibration-resistant multi-layer PCB

Engineering Advantages

Optimizes Front-End Rectification Management: The hardware links directly with the main drive processor to synchronize line-side silicon-controlled rectifier (SCR) or thyristor gating control sequences. This ensures balanced current draw across all incoming phases and minimizes total harmonic distortion back to the plant grid.
Streamlines High-Density Cabinet Layouts: Combining the active front-end rectifier timing circuitry and an 8-channel 24V DC digital subsystem onto a single 25.2cm x 19cm circuit board layout eliminates redundant interconnect cables, reducing physical failure points inside high-vibration drive bays.
Delivers Low-Noise Digital Isolation: The 8-channel onboard inputs draw a precise 5 mA per channel, providing crisp state changes that cut through aggressive ambient electrical noise. This design stops voltage spikes generated by heavy power switching from corrupting systemic logic data.
Maintains Rigorous Timing Profiles: The high-quality multi-layer PCB layout utilizes tight trace routing geometries to guarantee microsecond-level signal tracking. This strict execution prevents gate pulse asymmetries, protecting heavy SCR components from thermal overload during high-torque motor demands.

FAQs

Why do some industrial catalogs describe the 80190-380-01-R as a rotary motor resolver?

Legacy equipment inventory databases frequently contain cross-classification data errors that incorrectly assign generic servo resolver descriptions to specialized medium voltage drive parts. The 80190-380-01-R is explicitly a structural Rectifier Controller and Input Board assembly for PowerFlex drives, not a mechanical motor feedback sensor.
Can I replace an existing board that carries the base number 80190-378-51/12 with this unit?

Yes. The text string 80190-378-51/12 represents the raw unpopulated printed circuit board manufacture code, whereas 80190-380-01-R signifies the complete, fully populated, and tested final assembly. This brand-new 80190-380-01-R drops directly into slots using that raw board footprint.
Does this rectifier board require a separate software firmware flash upon installation?

No standalone firmware upload is required directly onto this card. The board receives its operational configurations and gate timing parameters dynamically from the primary PowerFlex 7000 main control module over the system bus during initial drive initialization.
