S9681DB-0 2-Channel 100 MHz Digital Oscilloscope Module

S9681DB-0 2-Channel 100 MHz Digital Oscilloscope Module

Availability: 10 left in stock

Yokogawa S9681DB-0 Digital Oscilloscope Module Configured for real-time waveform capture and fault recording in CENTUM VP platforms, the Yokogawa S9681DB-0...

SKU: S9681DB-0

Manufacturer: Yokogawa
Product No.: S9681DB-0
Product Type: Digital Oscilloscope Modules
Product Origin: JAPAN
Payment:T/T, Western Union
Weight: 550g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Yokogawa S9681DB-0 Digital Oscilloscope Module

Configured for real-time waveform capture and fault recording in CENTUM VP platforms, the Yokogawa S9681DB-0 (S9681DB Digital Oscilloscope Module) provides direct physical/electrical execution.

Hardware Specifications

Parameter	Specification
Model	S9681DB-0
Brand	Yokogawa
Origin	Japan
Weight	0.55 kg
Dimensions	140 x 50 x 120 mm
Operating Temp	-20 to 70 deg C
Power Consumption	12 W (at 24 VDC, 18-32 VDC range)
Channels	2 analog input channels (synchronous sampling)
Bandwidth	100 MHz
Sampling Rate	500 MS/s per channel (1 GS/s dual-channel mode)
Vertical Resolution	12-bit vertical precision
Input Impedance	1 Mohm plus or minus 1%
Memory Depth	1 Mpoints per channel

4-20 mA HART Loop Protocol and Channel-to-Channel Isolation

The module interfaces directly with high-speed industrial signals to monitor motor control loops, valve response transients, and power inverter waveforms. To prevent external electrical anomalies from damaging sensitive backplane processors, the system provides integrated channel-to-channel isolation and galvanic decoupling. The dual-channel synchronous sampling engine converts physical electrical fluctuations into digital files utilizing a 12-bit vertical resolution, which allows operators to verify loop impedance profiles and detect subtle signal distortions. This embedded diagnostic layer records transient events and system faults without adding latency to the main process control communication network.

Frequently Asked Questions

Q: Can this module function as a standalone desktop oscilloscope for lab verification?

A: No, the S9681DB-0 is an embedded system module that draws operating power directly from the Yokogawa DCS bus and requires integration within a compatible rack slot to execute control communication.

Q: How does the trigger system operate when monitoring transient electrical faults?

A: The onboard hardware triggers support edge, pulse width, video, and slope modes. When a signal violates the preconfigured threshold, the module captures and logs 1 Mpoints of high-resolution data per channel to the memory cache.

Q: What is the significance of the "-0" suffix in the model number?

A: The "-0" suffix indicates that this module is the standard industrial version built without intrinsic safety explosion protection. Engineers must route connections through external barriers if field cabling enters hazardous areas.

Field Installation Guidelines

Cabinet Environmental Protection: Mount the module within an IP20-rated, closed industrial cabinet, and ensure that local ambient temperatures remain within the -20 to 70 deg C operating limits.
Corrosive Atmosphere Resistance: In chemical or petrochemical facilities, seal the cabinet to utilize the G3 environmental compliance, protecting the internal electronics from accelerated sulfurous corrosion.
High-Speed Signal Shielding: Route all coaxial oscilloscope probe lines and signal inputs through dedicated, grounded steel wire ways to prevent electromagnetic interference (EMI) from corrupting the 100 MHz bandwidth measurements.
Bus Power Verification: Confirm that the 24 VDC backplane power supply remains stable within the 18 to 32 VDC input tolerance window before hot-plugging the card.
