6080165 HIMA HIMax HIMatrix Datasheet & Technical Manual

Safety Digital I/O Module | HIMA 6080165 HIMax HIMatrix

Safety Digital I/O Module | HIMA 6080165 HIMax HIMatrix

Availability: 99 left in stock

HIMA 6080165 HIMax HIMatrix Safety-Related Controller Module The HIMA 6080165, also cataloged as the 6080165 Safety-Related Controller Module, operates as...

SKU: 6080165

Manufacturer: HIMA
Product No.: 6080165
Product Type: Safety Digital I/O Modules
Product Origin: Germany
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

HIMA 6080165 HIMax HIMatrix Safety-Related Controller Module

The HIMA 6080165, also cataloged as the 6080165 Safety-Related Controller Module, operates as a dedicated hardware component for safety-critical digital input and output execution within HIMax and HIMatrix network architecture. It manages discrete signal processing and fault-tolerant trip logic while maintaining real-time system diagnostics over high-integrity field connections.

Hardware Specifications

Parameter	Specification
Model	6080165
Brand	HIMA
Origin	Germany
Weight	0.2 kg
Dimensions	120 x 80 x 30 mm
Operating Temp	-20 to +60 deg C
Power Consumption	24 VDC (Redundant input supported)
System Compatibility	HIMax / HIMatrix safety controllers
Channel Density	16 Digital channels (Configurable as input/output)
Communication Protocols	SafeEthernet, RS485
Diagnostic Coverage	Greater than 99% fault coverage
Safety Integrity Level	SIL3 (IEC 61508, IEC 61511)
Ingress Protection	IP20
Mounting Type	DIN rail / rack mounting

Triple Modular Redundancy (TMR) Architecture & Fail-Safe Execution

The HIMA 6080165 maintains a triple modular redundancy (TMR) 2oo3 architecture integration profile to guarantee fail-safe state execution across active process loops. Integrated galvanic isolation across all 16 digital channels isolates high-voltage electrical surges and prevents cross-talk interference from compromising logic solver operations.

Through continuous hardware self-testing, the module achieves greater than 99% diagnostic coverage. If an internal component or loop fault occurs, the board automatically forces affected outputs into a defined fail-safe state without dropping backplane network communication. Dual SafeEthernet and RS485 interfaces maintain deterministic signal transmission times under 10 ms across redundant control topologies.

Frequently Asked Questions

Q: Does the HIMA 6080165 support hot-swap replacement during system operation?

A: Yes. Technicians can replace the module online without interrupting power or data flow to adjacent I/O modules on the backplane rack.

Q: How does channel-to-channel galvanic isolation protect the logic solver core?

A: Galvanic isolation blocks high-voltage transients, stray ground loops, and field-side short circuits from traveling across terminal connections into the primary 24 VDC system bus.

Q: What action does the module take upon detecting an internal hardware fault?

A: Integrated self-diagnostics identify the fault within milliseconds and immediately drive the affected digital output channels into their predefined, de-energized fail-safe states.

Field Installation Guidelines

Mount the module on a standard DIN rail or rack assembly within an enclosure that meets field environmental requirements. Maintain at least 50 mm of vertical clearance above and below the module chassis to allow unimpeded convection cooling across the -20 to +60 deg C operating temperature range.

Route 24 VDC power conductors and digital signal wiring in separate wire ducts to prevent electromagnetic interference from coupling onto the I/O circuits. Connect the main ground wire to a low-impedance safety earth terminal using a short, heavy-gauge conductor strap. Verify all terminal block screw torque parameters before applying power to the primary DC bus.
