Spectrum Controls 1769sc-IT6I Series A Thermocouple Module

Availability: 99 left in stock

Product Description The 1769sc-IT6I (Series A) is a high-performance, 6-channel isolated thermocouple and millivolt input module designed for the Allen Bradley CompactLogix...

SKU: 1769sc-IT6I

Manufacturer: Allen Bradley
Product No.: 1769sc-IT6I
Product Type: Isolated Analog Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 350g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Description

The 1769sc-IT6I (Series A) is a high-performance, 6-channel isolated thermocouple and millivolt input module designed for the Allen Bradley CompactLogix and MicroLogix 1500 platforms. Developed by Spectrum Controls in collaboration with Rockwell Automation, this module provides superior noise immunity and precision for low-level signal acquisition in demanding industrial environments.

By utilizing individual channel-to-channel isolation, the 1769sc-IT6I (Series A) eliminates ground loop issues and protects the controller backplane from field-side electrical interference. This makes it an essential component for high-accuracy thermal monitoring in process control, furnace management, and energy regulation applications.

Detailed Technical Specifications

The 1769sc-IT6I (Series A) features programmable input filters and support for a wide array of sensor types, ensuring compatibility with virtually all standard industrial thermocouples.

Manufacturer: Allen-Bradley / Spectrum Controls
Model/Part Number: 1769sc-IT6I (Series A)
Module Type: Isolated Thermocouple / mV Analog Input
Number of Inputs: 6 individually isolated channels
Thermocouple Support: Types J, K, T, E, R, S, B, N, C, and L
Millivolt Range: ±50 mV and ±100 mV (Software selectable)
Resolution: 16-bit
Isolation Rating: * 125 VAC channel-to-channel

125 VAC field-wiring-to-backplane
125 VAC field-wiring-to-chassis-ground

Input Impedance: > 1 MΩ
Input Filter Frequencies: 4.17 Hz, 10 Hz, 16.7 Hz, 19.6 Hz, 62 Hz, and 470 Hz
Channel Update Time: 0.244s to 0.006s (Filter dependent)
Backplane Current Draw: 150 mA @ 5V DC; 35 mA @ 24V DC
Overvoltage Protection: ±35 VDC continuous
Operating Temperature: 0°C to +60°C (32°F to 140°F)
Certifications: UL/cUL Listed, CE, ANSI/ISA 12.12.01 (Class I, Div 2)
