TC-TBCH Honeywell DCS Rack Mount Termination Assembly

Availability: 20 left in stock

Product Overview The TC-TBCH is an authoritative hardware component designed for Honeywell Experion PKS and TDC 3000 distributed control systems (DCS). It...

SKU: TC-TBCH

Manufacturer: Honeywell
Product No.: TC-TBCH
Product Type: Termination Assembly Chassis
Product Origin: USA
Payment:T/T, Western Union
Weight: 5000g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The TC-TBCH is an authoritative hardware component designed for Honeywell Experion PKS and TDC 3000 distributed control systems (DCS). It serves as a high-density Termination Assembly (TA) Chassis, providing the essential mechanical and electrical infrastructure for mounting Input/Output Termination Assemblies (IOTA) and I/O modules. The TC-TBCH acts as the physical backbone for field wiring, ensuring that signals from transmitters, switches, and sensors are organized and securely routed to the system backplane. Engineered for the 24/7 reliability required in refineries, chemical plants, and power utilities, this chassis facilitates clean cable management and robust power distribution across connected automation hardware.

Detailed Technical Specifications

Attribute	Details
Manufacturer	Honeywell
Model Number	TC-TBCH
Product Type	Termination Assembly (TA) Chassis
System Compatibility	Honeywell Experion PKS, TDC 3000
Capacity	Typically supports up to 8–16 IOTA slots (config dependent)
Input Connection	36-Pin Terminal Block interface
Mounting Format	Standard 19-inch Rack Mount / Cabinet Installation
Material	Industrial-grade heavy-duty metal with corrosion-resistant coating
Cable Management	Integrated routing guides and securing tie-points
Operating Temperature	0 °C to +60 °C (32 °F to 140 °F)
Operating Humidity	5% to 95% Non-condensing
Dimensions	482 mm (W) x 200 mm (H) x 250 mm (D)
Weight	5.0–7.0 kg (11–15.4 lbs)
Certifications	CE, UL, CSA Industrial Compliance

Installation Guide

Chassis Mounting: Install the TC-TBCH into a standard 19-inch equipment rack or control cabinet. Ensure the mounting ears are securely fastened using M6 or equivalent rack screws to prevent vibration-induced fatigue.
Module Seating: Insert the corresponding IOTA/IOM modules into the vertical slots of the chassis. A mechanical necessity is the proper alignment of the backplane connectors before applying seating pressure to avoid pin damage.
Field Wiring Integration: Route field cables through the integrated cable management guides. Terminate wires to the 36-pin blocks or specific IOTA terminals as per the system loop drawings.
Power Distribution: Connect the system power supply to the chassis backplane power terminals. Ensure the 24VDC rails are regulated and that the chassis is bonded to the plant safety ground for authoritative noise immunity.
Verification: Perform a point-to-point continuity check between the field sensors and the TC-TBCH terminals to ensure signal integrity before commissioning the associated I/O modules.

Technical FAQ

What is the difference between a TC-TBCH and a standard terminal strip?

The TC-TBCH is an active component of the Honeywell DCS infrastructure. Unlike a passive terminal strip, it provides a synchronized electrical backplane for I/O modules, making it a mechanical necessity for high-speed data exchange and integrated power distribution.

Can this chassis be used in redundant configurations?

Yes. In mission-critical environments, TC-TBCH units are frequently deployed in pairs to support redundant IOTA configurations, ensuring that if one communication path or module fails, the secondary remains authoritative.

Does the TC-TBCH require special maintenance?

Maintenance is minimal, but periodic checks of terminal torque and inspection for dust accumulation on the backplane connectors are recommended to ensure a trustworthy electrical path in harsh industrial environments.
