Woodward 5462-757 Digital Input Module with LED Indication

Availability: 99 left in stock

Product Overview The Woodward 5462-757 (Rev D) functions as a high-density Discrete Input Module within the MicroNet Digital Control platform....

SKU: 5462-757

Manufacturer: Woodward
Product No.: 5462-757
Product Type: Woodward MicroNet Series
Product Origin: USA
Payment:T/T, Western Union
Weight: 295g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Woodward 5462-757 (Rev D) functions as a high-density Discrete Input Module within the MicroNet Digital Control platform. This 100% Brand New hardware expansion provides 28 independent channels designed to monitor the status of field switches, relay contacts, and digital sensors. It plays a critical role in sequencing logic for gas and steam turbines, allowing the central controller to detect binary states such as "Open/Closed," "Start/Stop," or "Fault/Normal" with high-speed deterministic accuracy. By integrating real-time LED status indicators directly on the faceplate, the 5462-757 significantly streamlines the commissioning and troubleshooting of complex industrial control loops.

Technical Specifications

Parameter	Specification Details
Model Number	5462-757 (Revision D)
Manufacturer	Woodward
Input Channels	28 Independent Discrete Inputs
Visual Diagnostics	Individual LED Status Indication per Channel
Input Type	Optically Isolated Discrete Inputs
Platform	MicroNet / MicroNet Plus Digital Control System
Mounting	MicroNet Chassis Slot
Shipping Weight	2.0 kg (4.4 lbs)
Net Weight	0.65 lbs (Module Only)
Operating Temp	-40 to +70 deg C (Standard Industrial Range)

Engineering Advantages

High-Density Signal Monitoring: The 28-channel architecture allows for extensive system monitoring within a single chassis slot. This maximizes I/O density in crowded control cabinets, reducing the total hardware footprint required for large-scale power generation or marine propulsion projects.
Instantaneous Visual Diagnostics: Each of the 28 channels includes a dedicated LED indicator. These LEDs provide maintenance personnel with immediate visual confirmation of field-side contact states, effectively cutting down the time required to diagnose wiring faults or failed field switches without the need for an external laptop.
Robust Signal Isolation: The 5462-757 utilizes high-grade optical isolation for every input channel. This design prevents electrical transients and ground loop noise originating in the field from reaching the MicroNet backplane, thereby protecting the core CPU and sensitive control logic from hardware damage.
Seamless Legacy Integration: Despite its "Discontinued by Manufacturer" status, the 5462-757 Rev D remains fully compatible with existing MicroNet infrastructures. This allows facilities to perform direct "hot-swap" replacements (under proper procedures) to maintain legacy systems without requiring expensive software migrations or cabinet rewiring.

FAQs

Can I replace a 5462-757 Rev A or B with this Rev D module?

Yes. Woodward Revision D modules typically offer backward compatibility. The Rev D version includes circuit refinements that improve thermal stability and signal filtering over earlier revisions while maintaining the same physical and logical interface.

What type of field contacts are compatible with this module?

The module accepts standard dry contact or voltage-sensing inputs. It monitors the state of limit switches, pushbuttons, and auxiliary relay contacts commonly found in turbine and compressor control circuits.

Does the 5462-757 require external power for the LED indicators?

No. The module draws the necessary power for its internal logic and LED indication directly from the MicroNet chassis backplane, ensuring that status indicators remain active as long as the control system is energized.

How do I verify a channel is working if the LED is off?

First, verify the field voltage at the terminal block. If voltage is present at the input but the LED is dark, check the software configuration to ensure the channel is not disabled. If the hardware persists in not showing state changes, the optical isolator for that specific channel may require inspection.
