Woodward 5464-211 MicroNet High-Density Digital Output

Availability: 10 left in stock

Product Overview The Woodward 5464-211 functions as a high-density Discrete Output module within the MicroNet Digital Control System platform. This module provides...

SKU: 5464-211

Manufacturer: Woodward
Product No.: 5464-211
Product Type: Discrete Output Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 1080g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Woodward 5464-211 functions as a high-density Discrete Output module within the MicroNet Digital Control System platform. This module provides 32 independent, isolated channels designed to drive field equipment such as solenoid valves, relays, motor starters, and alarm indicators. By converting low-level logic commands from the MicroNet CPU into robust 24V DC output signals, the 5464-211 enables precise actuation of critical safety and process control loops in turbine and engine applications.

Condition: This product is 100% Brand New, original Woodward factory stock, and ready for immediate shipment.

Technical Specifications

The 5464-211 module utilizes advanced optical and electrical isolation to protect the system backplane from field-side electrical noise and transients.

Parameter	Details
Manufacturer	Woodward
Model Number	5464-211
Output Channels	32 Isolated Discrete Outputs
Output Voltage Range	24 VDC Nominal
Output Type	Transistor (Configurable Sourcing/Sinking)
Load Capacity	Up to 0.5 A per channel
Isolation	Channel-to-Logic Optical & Electrical Isolation
Status Indicators	Front-panel LEDs for every channel
Operating Temperature	-40°C to +85°C
Storage Temperature	-55°C to +100°C
Dimensions	2.6 cm x 24.8 cm x 26.2 cm
Unit Weight	1.08 kg
Compliance	CE, UL, CSA, ATEX/IECEx

Engineering Advantages

High-Density Rack Efficiency: Packing 32 output points into a single MicroNet slot significantly reduces the hardware footprint. This allows engineers to design smaller control cabinets or expand existing system capabilities without adding additional racks.
Robust Fault Isolation: Optical and electrical barriers isolate the field wiring from the sensitive MicroNet logic bus. This prevents localized field wiring faults, such as short circuits or inductive kicks, from propagating through the system and causing a processor failure.
Superior Thermal Performance: Designed for extreme industrial environments, the module operates reliably in temperatures ranging from -40°C to +85°C. This wide thermal envelope makes it ideal for turbine enclosures and remote engine stations where cooling may be limited.
Simplified Troubleshooting: The front-panel LED array provides instantaneous visual verification of every output state. Maintenance personnel can identify failed coils or broken field wiring at a glance without probing backplane signals.
Fast Response Actuation: The solid-state transistor architecture ensures high-speed switching. This deterministic response is vital for time-sensitive operations like turbine trip sequences or emergency valve closures.

FAQs

Can the 5464-211 drive inductive loads like large solenoids?

Yes. Each channel supports up to 0.5 A, which covers most industrial solenoids and relays. However, for highly inductive loads, we recommend verifying the flyback protection at the field device to maximize the longevity of the module’s transistor outputs.
Is this module hot-swappable?

While the MicroNet platform supports advanced maintenance features, you should always follow the specific Woodward MicroNet hardware manual procedures regarding rack power and module replacement to prevent data corruption or hardware damage.
Does the 5464-211 require external power for the outputs?

Yes. The module requires a 24V DC external field power source to drive the loads. The internal backplane power only operates the logic and isolation circuitry.
How do I configure the module for sourcing vs. sinking outputs?

Configuration depends on the wiring of the common terminals on the Field Terminal Module (FTM) associated with the 5464-211. Consult your system's wiring diagram for the specific FTM model used in your installation.
