ADV551-P60/D5A00 Yokogawa Digital Output Module

Yokogawa ADV551-P60/D5A00 CENTUM VP Digital Output Module

Yokogawa ADV551-P60/D5A00 CENTUM VP Digital Output Module

Availability: 20 left in stock

Yokogawa ADV551-P60/D5A00 Digital Output Module Configured for high-speed signal actuation in CENTUM VP control system platforms, the Yokogawa ADV551-P60/D5A00 (ADV551...

SKU: ADV551-32DO

Manufacturer: Yokogawa
Product No.: ADV551-32DO
Product Type: Digital Output Modules
Product Origin: JAPAN
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Yokogawa ADV551-P60/D5A00 Digital Output Module

Configured for high-speed signal actuation in CENTUM VP control system platforms, the Yokogawa ADV551-P60/D5A00 (ADV551 Digital Output Module) provides direct physical/electrical execution.

Suffix Breakdown & Model Matrix

The suffix structure defines functional features and system termination hardware for the ADV551 base platform:

P: Specifies integrated pulse width output and time-proportional output execution functions.
6: Indicates front status display functionality with standard non-explosion-proof housing construction.
0: Designates the standard base module layout.
D5A00: Incorporates the factory KS Cable Interface Adapter designed for 32-channel digital field connections.

Hardware Specifications

Parameter	Specification
Model	ADV551-P60/D5A00
Brand	Yokogawa
Origin	France / Japan
Weight	0.2 kg
Dimensions	27.4 cm x 6.4 cm x 12.7 cm
Operating Temp	-20 deg C to +55 deg C
Power Consumption	700 mA at 5 VDC, 60 mA at 24 VDC external
Output Channels	32 isolated digital outputs
Output Voltage	24 VDC nominal
Output Type	Transistor output (sink/source configurable)
Load Current	Up to 0.5 A per channel
Response Time	<= 1 ms typical
Isolation	2000 VAC withstand (channel-to-channel and channel-to-system)

Channel-to-Channel Isolation & DCS Loop Management

The hardware incorporates optoelectronic isolation barriers rated for 2000 VAC withstand, preventing ground loops and transient noise propagation across system backplane buses. Engineered to operate in close proximity to sensitive 4-20 mA HART loop protocol wiring and analog instruments, each output channel isolates electrical transients generated during switching operations. Individual short-circuit and overload protection circuits prevent field faults from compromising adjacent channels, maintaining signal stability for high-density valve actuators and interlock relays.

Frequently Asked Questions

Q: Does the module support online extraction while the DCS chassis is powered?

A: Yes, operators can perform online hot-swap replacements without removing backplane power or disturbing adjacent active I/O cards, provided standard field wiring removal steps are followed.

Q: How does the module handle overcurrent conditions on an active output channel?

A: Each output circuit features short-circuit and thermal overload protection. When an overcurrent state occurs, the module isolates the fault to the affected line while adjacent channels remain operational.

Field Installation Guidelines

Align the module edge connector with the designated slot on the CENTUM VP rack and push firmly until the locking mechanisms engage fully. Connect the KS interface cable directly to the front terminal block adapter, ensuring all retention screws are hand-tightened. Connect signal shielding conductors to the single-point cabinet ground bus to mitigate ground potential loops. Route 24 VDC field actuator cables separately from low-voltage analog wiring inside the enclosure ducts to suppress cross-talk and electromagnetic interference.
