F3AD08-5V Yokogawa Analog Input Module

Yokogawa F3AD08-5V FA-M3 Analog Input Module

Yokogawa F3AD08-5V FA-M3 Analog Input Module

Availability: 10 left in stock

Yokogawa F3AD08-5V Analog Input Module Configured for high-speed voltage telemetry acquisition in FA-M3 PLC platforms, the Yokogawa F3AD08-5V (F3AD08 Analog...

SKU: F3AD08-5V

Manufacturer: Yokogawa
Product No.: F3AD08-5V
Product Type: Analog Input Modules
Product Origin: JAPAN
Payment:T/T, Western Union
Weight: 120g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Yokogawa F3AD08-5V Analog Input Module

Configured for high-speed voltage telemetry acquisition in FA-M3 PLC platforms, the Yokogawa F3AD08-5V (F3AD08 Analog Input Module) provides direct physical/electrical execution across industrial backplane networks.

Hardware Specifications

Parameter	Specification
Model	F3AD08-5V
Brand	Yokogawa
Origin	Japan
Weight	0.12 kg
Dimensions	28.9 x 100 x 83.2 mm
Operating Temp	0 to +55 deg C
Power Consumption	~100 mA (draws from 5 VDC backplane rail)
Input Channels	8 voltage channels
Signal Range	0-5 V DC (selectable 0-10 V DC, -10 to +10 V DC)
A/D Resolution	12-bit analog-to-digital conversion
Accuracy	+/-0.2% of full scale
Sampling Speed	1 ms per channel
Galvanic Isolation	Photocoupler isolation (channels to system backplane)

DCS Process Control & Transmitter Loop Interfaces

The F3AD08-5V module converts field voltage signals into 12-bit digital values, transferring real-time measurement arrays directly across the internal FA-M3 bus. Onboard photocoupler barriers deliver galvanic isolation between field input terminals and the central processing backplane, preventing severe voltage transients from damaging logic circuits. Furthermore, internal sampling routines execute continuous 1 ms conversion cycles per channel, suppressing high-frequency industrial electromagnetic interference and eliminating localized ground loops without degrading overall scan execution rates.

Frequently Asked Questions

Q: How does the F3AD08-5V isolate internal logic from field wiring surges?

A: Integrated photocoupler isolation barriers physically separate the 8-channel field wiring terminals from the internal 5 VDC system backplane bus, attenuating common-mode voltage spikes.

Q: What happens if an input signal exceeds the maximum designated voltage range?

A: Onboard diagnostic firmware detects over-range conditions, triggers an internal channel error flag in the system registers, and limits data overflow without interrupting adjacent channel sampling cycles.

Q: Is external power required to operate the analog-to-digital conversion circuits?

A: No, the module draws its operational supply directly from the FA-M3 PLC backplane bus, consuming approximately 100 mA at 5 VDC.

Field Installation Guidelines

Align the module circuit board with the guide rails of the designated FA-M3 base slot and push firmly until the upper retaining clip snaps into position.
Route analog signal wiring through shielded twisted-pair cables (AWG22 to AWG16) to minimize industrial noise pickup.
Terminate all cable shield drain conductors to a single functional grounding point on the main enclosure earth bus bar.
Maintain a minimum clearance of 100 mm between low-voltage analog input lines and high-current AC power cables inside wire troughs.
Tighten terminal block connection screws to a standard torque specification of 0.5 to 0.6 Nm to prevent thermal loosening over prolonged operation.
