ABB DSQC335 3HAB6182-1 IRC5 Robot Digital I/O Interface Module

Availability: 10 left in stock

ABB DSQC335 Digital I/O Interface Module Configured for high-density signal integration in IRC5 robot work cells, the ABB DSQC335 (3HAB6182-1...

SKU: DSQC335

Manufacturer: ABB
Product No.: DSQC335
Product Type: Digital I/O Interface Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 400g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

ABB DSQC335 Digital I/O Interface Module

Configured for high-density signal integration in IRC5 robot work cells, the ABB DSQC335 (3HAB6182-1 Digital I/O Interface Module) provides direct physical signal exchange via the DeviceNet fieldbus protocol.

Suffix Breakdown & Model Matrix

Model	Description
DSQC335	Digital I/O Interface Module
3HAB6182-1	Standard variant for DeviceNet node communication

Hardware Specifications

Parameter	Specification
Model	DSQC335
Brand	ABB
Origin	Sweden
Weight	0.4 kg
Dimensions	2.0 cm x 24.1 cm x 25.4 cm
Operating Temp	0 deg C to 55 deg C
Power Consumption	24 VDC
I/O Capacity	16 Configurable channels
Protocol	DeviceNet
Output Type	24 VDC Transistor (High-side)
Isolation	Opto-isolated

Robot Controller Deterministic Networks and Firmware

The DSQC335 acts as a deterministic DeviceNet slave, facilitating cyclic data exchange with the IRC5 robot controller. The module features dual rotary switches for manual network node addressing (0-63), ensuring predictable communication timing within the controller's DeviceNet Lean or Master/Slave software environment. Optical isolation between the fieldbus side and the process side maintains electrical noise immunity, preventing backplane-to-field transients from impacting logic execution. The unit’s internal logic is configured via physical DIP switches, providing high-speed response times for I/O mapping that remains static and consistent across every scan cycle of the robotic motion task.

Frequently Asked Questions (FAQ)

Q: Can the 16 I/O points be reconfigured while the IRC5 controller is running?

A: No. The I/O channel configuration (e.g., input vs. output ratios) is determined by the physical DIP switches on the module. Any changes to the DIP switch settings require the controller to be de-energized, followed by a system reboot for the new configuration to be recognized by the software.

Q: How is the node address of the DSQC335 assigned?

A: The DeviceNet node address is assigned via the two front-facing rotary switches. Ensure the address is unique within the DeviceNet network to avoid bus communication conflicts during robot operation.

Field Installation Guidelines

Mounting: Utilize the compact profile of the DSQC335 to maintain high-density mounting within the IRC5 cabinet. Ensure adequate spacing between modules to prevent heat accumulation.
Addressing: Set the DeviceNet node address before installing the module in the cabinet rack. Verify that the address matches the configuration defined in the RobotStudio I/O setup.
Wiring: Connect 24 VDC power and signal lines using shielded cables. Ensure the cable shields are correctly bonded to the controller cabinet ground busbar to maintain the integrity of the opto-isolation and minimize EMI/RFI impact.
Validation: After installation, monitor the device status LEDs. A solid green light indicates established network communication; a flashing or red light indicates a configuration mismatch or communication fault that must be addressed before enabling the robot motion tasks.
