Buy Brand New Yokogawa F3YD14-0N PLC Output Module

Availability: 99 left in stock

Product Overview The Yokogawa F3YD14-0N serves as a high-capacity digital output interface for the FA-M3 Range-free Multi-controller platform. Designed for heavy-duty industrial...

SKU: F3YD14-0N

Manufacturer: Yokogawa
Product No.: F3YD14-0N
Product Type: FA-M3 PLC Series
Product Origin: JAPAN
Payment:T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Yokogawa F3YD14-0N serves as a high-capacity digital output interface for the FA-M3 Range-free Multi-controller platform. Designed for heavy-duty industrial switching, this module features 14 transistor outputs that deliver an impressive 1.2 A per channel. It acts as the primary power driver for high-load field devices including large solenoid valves, contactors, and heavy-duty relays. By integrating high current handling with a compact form factor, the F3YD14-0N eliminates the need for external buffer circuits in demanding factory automation and robotics applications.

Condition Statement: We supply the F3YD14-0N in 100% Brand New, Factory Sealed Original condition to ensure maximum service life and adherence to strict industrial safety standards.

Technical Specifications

The F3YD14-0N balances high channel density with superior thermal management to support a massive 16 A total module aggregate.

Parameter	Specification
Output Channels	14 Channels
Output Type	Transistor (Sink/Source Compatible)
Rated Voltage	24V DC
Max Current per Channel	1.2 A
Total Module Current	16 A (Maximum Aggregate)
Response Time	< 1 ms (OFF to ON / ON to OFF)
Isolation Method	Photocoupler Isolation (Field-to-System)
Withstand Voltage	500V AC for 1 minute
Internal Power Draw	100 mA @ 5V DC
Dimensions	28.9 (W) x 100 (H) x 83.2 (D) mm

Engineering Advantages

The F3YD14-0N addresses specific hardware integration challenges in high-speed production environments:

Direct Load Actuation: Most PLC output modules limit current to 0.5 A or less, requiring interposing relays for larger loads. The 1.2 A rating per channel on the F3YD14-0N allows you to drive heavy solenoids directly, significantly reducing cabinet wiring complexity and hardware costs.
Precision Timing: The photocoupler-isolated circuitry achieves response times under 1 ms. This rapid switching supports the tight synchronization required for high-speed bottling, packaging, and sorting lines where milliseconds impact throughput.
Electronic Noise Immunity: High-current switching often generates significant electromagnetic interference (EMI). Photocoupler isolation provides a physical light-gap barrier between the field-side 24V DC and the PLC backplane, protecting your FA-M3 processor from voltage spikes and ground loops.
High-Density Thermal Management: Despite its slim 28.9 mm profile, the module incorporates an optimized heat dissipation design. It maintains a stable 16 A total output across all channels without causing thermal stress to adjacent modules in the PLC rack.

FAQs

Can the F3YD14-0N replace the 8-channel F3YD08 modules?

Yes. The F3YD14-0N provides a higher channel density and increased current capacity per point. When upgrading, verify that your wiring harness accommodates the 14-pin configuration to ensure a seamless transition.
Is this module compatible with both NPN and PNP field wiring?

The F3YD14-0N supports versatile transistor wiring configurations. However, you must consult the terminal diagram for your specific field device polarity (Sink vs. Source) to ensure the common line matches correctly.
Does the module draw its output power from the PLC backplane?

No. While the PLC backplane provides 100 mA at 5V DC for the internal logic, you must connect an external 24V DC power supply to the field-side terminals to drive the connected actuators.
What is the benefit of the 500V AC withstand voltage?

This rating indicates the module's ability to withstand high-voltage surges between the field wiring and the system logic. It ensures that a short circuit or catastrophic failure in an external field device will not destroy the expensive PLC CPU.
